330105-XX-XX-05-02-05 Bently Nevada Eddy Current Probe

Bently Nevada 330105-XX-XX-05-02-05 MOD:164265-01 3300 XL 8 mm Reverse Mount Probes

Technical Specifications

• Brand: Bently Nevada
• Model: 330105-XX-XX-05-02-05 MOD:164265-01
• Series: 3300 XL 8 mm Reverse Mount Probes
• Category: Eddy Current Probes
• Total Length: 05 = 0.5 meter (1.6 feet)
• Connector: 02 = Miniature ClickLoc coaxial connector
• Agency Approval: 05 = CSA, ATEX, IECEx Approvals
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Case Material: AISI 303 or 304 stainless steel (SST)
• Nominal Probe DC Resistance: 7.45 ± 0.50 Ω from center conductor to outer conductor at 0.5 m
• Probe Case Thread: 3/8-24 UNF
• Maximum Thread Engagement Length: 0.563 in
• Probe Weight: 323 g/m (11.4 oz)
• Standard Cable: 75 Ω triaxial, FEP insulated
• Extended Temperature Cable: 75 Ω triaxial, PFA insulated
• Armor Option: Flexible AISI 302 or 304 SST with FEP outer jacket
• Connector Material: Gold-plated brass or gold-plated beryllium copper
• Maximum Tensile Strength: 330 N (75 lbf) probe case to probe lead; 270 N (60 lbf) at probe lead to extension cable connectors
• Operating and Storage Temperature: Standard probe: -52°C to +177°C (-62°F to +350°F)
• Extended Temperature Range: Probe tip: -52°C to +218°C (-62°F to +425°F); cable and connector: -51°C to +260°C (-60°F to +500°F)
• Low Temperature Caution: Exposing the probe below –34°C (-30°F) may cause premature pressure seal failure
• Pressure Seal: Viton® O ring seals differential pressure between probe tip and case
• Relative Humidity: Less than 3% change in Average Scale Factor (ASF) at 93% humidity per IEC 68-2-3 for up to 56 days

Installation Guide

• Verify the 3/8-24 UNF thread matches your mounting hole before installation.
• Keep the maximum thread engagement at 0.563 in to avoid case damage.
• Use the miniature ClickLoc coaxial connector to secure the cable link.
• Route the 0.5 meter probe cable away from high electrical noise sources.
• Respect the -52°C to +177°C standard operating range for stable readings.
• Avoid bending the cable below its minimum bend radius during routing.
• Confirm the probe DC resistance near 7.45 Ω before powering the system.
• Do not expose the probe to temperatures below –34°C to protect the pressure seal.

Package List

• 1 × Bently Nevada 330105-XX-XX-05-02-05 MOD:164265-01 probe
• 1 × Miniature ClickLoc coaxial connector (pre-installed)
• 1 × 0.5 meter probe cable (pre-attached)
• 1 × Protective shipping box

Shipping and Support

• We keep this probe in stock for immediate order processing.
• We ship within 5 days after payment confirmation.
• We use FedEx, UPS, and DHL for global delivery.
• We support 30-day returns for eligible orders.
• We provide new original products only.

FAQ

• Q: What is the cable length of this probe?
  A: The total length option 05 gives you 0.5 meter (1.6 feet).
• Q: Which connector does this probe use?
  A: It uses a miniature ClickLoc coaxial connector for a secure link.
• Q: What is the nominal DC resistance?
  A: The probe shows 7.45 ± 0.50 Ω from center to outer conductor.
• Q: What is the standard operating temperature range?
  A: The standard probe operates from -52°C to +177°C (-62°F to +350°F).
• Q: Does this probe carry agency approvals?
  A: Yes, option 05 includes CSA, ATEX, and IECEx approvals.
• Q: What is the maximum tensile strength?
  A: It reaches 330 N (75 lbf) from probe case to probe lead.
• Q: How fast do you ship?
  A: We ship within 5 days using FedEx, UPS, or DHL.
• Q: Can I return the product?
  A: Yes, we support 30-day returns for eligible orders.
