Schneider Electric ATV61HC11N4 150HP Variable Speed Drive 460V

Schneider Electric Altivar 61 Variable Speed Drive - 150 HP

Core Technical Specifications

• Brand & Model: Schneider Electric ATV61HC11N4 from the Altivar 61 range.
• Motor Power: Rated for 110 kW (150 HP) three-phase asynchronous or synchronous motors.
• Supply Voltage: Wide three-phase input range from 380 to 480 VAC.
• Output Current: Delivers a continuous 215 A at 2.5 kHz switching frequency (380-460V).
• Control Methods: Supports sensorless flux vector control and multiple U/f profiles for precision.
• EMC Filter: Includes a built-in Level 3 EMC filter for enhanced electromagnetic compatibility.

Key Features & Performance

• Communication & Connectivity: Native support for Modbus and CANopen. Extensive optional cards available for Profibus DP, EtherNet/IP, DeviceNet, and more.
• I/O Configuration: Features 2 analog inputs (voltage/current), 1 analog output, and 7 discrete inputs (including one safety input).
• Relay Outputs: Two configurable relay outputs (R1: NO/NC, R2: NO) with high switching capacity.
• Protection & Safety: Comprehensive protection includes Safe Torque Off (STO), thermal overload, phase loss, and short-circuit safeguards.
• Environmental Rating: Robust construction with IP41 rating on the upper part and IP54 on the lower part for challenging environments.

Installation & Wiring Guide

• For power connections (L1/R, L2/S, L3/T, U/T1, V/T2, W/T3), use terminals sized for 2 x 100 mm² (2 x 250 kcmil) cables.
• Control terminals (AI, AO, LI, R) require 2.5 mm² (AWG 14) conductors.
• Apply correct tightening torque: 24 N.m for power terminals and 0.6 N.m for control terminals.
• Install vertically (±10°) in an ambient temperature range of -10°C to +45°C for full performance without derating.

Frequently Asked Questions (FAQ)

• What is the horsepower rating of this VFD?
  The Schneider Electric ATV61HC11N4 is rated for 150 Horsepower (110 kW) motors.
• Is this drive suitable for pump control?
  Yes, the Altivar 61 series is specifically designed for pumping and ventilation applications, making it an ideal choice.
• What communication protocols come standard?
  This drive supports Modbus and CANopen communication protocols directly. Many other industrial networks are available via optional plug-in cards.
• Does it include a safety function?
  Yes, it features a dedicated safety input (PWR) that supports Safe Torque Off (STO) functionality for enhanced personnel safety.
• What is the IP protection rating?
  The drive offers an IP41 rating on the upper section and a higher IP54 rating on the lower section, protecting against dust and water spray.
• Are these drives in stock?
  Yes, we maintain stock of the ATV61HC11N4 to ensure prompt shipment.
• What are the shipping options and time?
  We ship worldwide via major carriers (DHL/FedEx/UPS) and dispatch most orders within 5 working days.

For technical specifications, pricing, or to place an order, please get in touch with our sales team.
