Bently Nevada 3300 NSv Probe 330905-00-08-05-12-05

Bently Nevada 330905-00-08-05-12-05 3300 NSv Proximity Probe with FluidLoc Cable

Product Overview & Key Features

• The Bently Nevada 3300 NSv probe ensures dependable operation in continuous monitoring applications.
• This model comes with a FluidLoc cable for improved performance in fluid-exposed environments.
• It holds multiple agency approvals (Option -05), meeting stringent international standards.
• The probe offers superior side-view characteristics for precise installation and gap setting.
• It maintains full mechanical and electrical interchangeability with the legacy 3300 RAM probe system.
• Every unit is supplied in sealed, original factory packaging, guaranteeing authenticity and peak performance.

Complete Model Suffix Information

The detailed part number 330905-00-08-05-12-05 defines this exact probe configuration:

• Basic Model: 330905 - 3300 NSv Probe, M10X1 thread, without armor
• Unthreaded Length: 00 - 0 mm
• Case Length: 08 - 80 mm
• Total Length: 05 - 0.5 meter (20 inches) cable
• Connector/Cable: 12 - Miniature coaxial ClickLoc connector with FluidLoc cable
• Agency Approval: 05 - Multiple Approvals

Technical Specifications

• Brand: Bently Nevada
• Model: 330905-00-08-05-12-05 (3300 NSv Series)
• Linear Range: 1.5 mm (60 mils), effective from 0.25 to 1.75 mm from target.
• Recommended Gap: 1.0 mm (40 mils).
• Sensitivity (ISF): 7.87 V/mm (200 mV/mil) with specified tolerances.
• Linearity (DSL): Better than ±0.06 mm (±2.3 mils) across the linear range.
• Frequency Response: 0 to 10 kHz, stable performance with long field wiring.
• Probe Tip Material: Durable Polyphenylene Sulfide (PPS).
• Probe Case Material: AISI 304 Stainless Steel, M10x1 thread.
• Operating Temperature: -52°C to +177°C (-62°F to +351°F).
• Cable Type: 75 Ω coaxial with FEP insulation, FluidLoc version.
• Connector: Miniature coaxial ClickLoc connector.
• Min. Target Size: 8.9 mm diameter (13 mm recommended).
• Probe DC Resistance: 4.0 ± 0.5 ohms (for 0.5m cable length).
• Agency Approvals: Certified to multiple international standards (Option -05).

Frequently Asked Questions (FAQ)

• Q: What is special about the '12' cable option?
  A: Option '12' specifies a FluidLoc cable, designed for enhanced performance in environments where fluid exposure is a concern.
• Q: What does agency approval '05' mean?
  A: The '-05' suffix indicates this 330905-00-08-05-12-05 probe carries multiple international safety and quality certifications.
• Q: Is this probe compatible with my existing system?
  A: Yes. This 3300 NSv probe is a direct, plug-and-play replacement for older 3300 RAM probes and is compatible with standard extension cables.
• Q: What is the lead time for this model?
  A: This configuration is typically in stock. We aim to dispatch all orders within 5 business days.
• Q: How do I install this probe correctly?
  A: Hand-tighten the probe, then use a torque wrench to a maximum of 0.56 N•m (5 in•lb). Ensure proper thread engagement and avoid exceeding the cable's minimum bend radius.
• Q: What is your warranty and return policy?
  A: The product includes a 12-month factory warranty. We also offer a 30-day return window for items in original, unopened condition.

For complete technical details, installation guides, and agency approval specifics: Download the Official 3300 XL NSv Proximity Transducer System Datasheet (PDF)
