Schneider Electric 140EIA92100 AS-Interface Master Module

Schneider Electric Modicon Quantum AS-Interface Master Module

Key Product Specifications

• Brand & Model: This is the 140EIA92100 model from Schneider Electric's Modicon Quantum series.
• Network Capacity: The module supports up to 31 slave devices and 248 total I/O points (124 In / 124 Out).
• System Performance: It offers a very fast maximum cycle time of just 5 milliseconds for rapid control.
• Communication & Supply: Data transfers at 167 kbit/s over 100 meters and is powered directly from the 30 V DC AS-i bus.
• Module Integration: You can install up to 2 modules in a distributed drop or 4 in local/remote drops on a Quantum PLC.

Physical Design & Operating Environment

• The unit has built-in reverse polarity protection to prevent wiring errors.
• 32 status LEDs show slave addresses and I/O bit states for instant visual diagnostics.
• Connection is made via a robust 9-pin male SUB-D connector for the AS-i network cable.
• It carries an IP20 protection rating for use in controlled industrial environments.
• Safe operation is ensured within an ambient temperature range of 0°C to 60°C.

Frequently Asked Questions (FAQ)

• Q: What is the exact model number of this AS-i master?
  A: The official model is the Schneider Electric 140EIA92100.
• Q: How many digital devices can I connect to this master?
  A: You can connect a network with a maximum capacity of 124 inputs and 124 outputs.
• Q: Does the module need a separate power supply?
  A: No, it receives operating power directly from the 30V DC AS-Interface bus line.
• Q: Is this item in stock for quick delivery?
  A: Yes, we have this module in stock for immediate order processing.
• Q: What is your standard shipping time after order?
  A: We process and ship all orders within 5 business days.
• Q: Which courier services do you use?
  A: We typically ship internationally via DHL, FedEx, or UPS.
• Q: What is the policy if I need to return the product?
  A: We offer a 30-day return policy for unused items in original packaging.
