IS215VCMIH2C GE Mark VI VME Bus Master Controller Board

IS215VCMIH2C VCMI Bus Master Controller – GE Mark VI

Technical Specifications

• Brand: General Electric
• Model: IS215VCMIH2C
• Series: Mark VI
• Product Type: VME Bus Master Controller Board
• Board Type: 6U
• Processor: 32-bit with dual-port memory
• Number of Channels: 12
• Analog Output Current: 0-20 mA
• Frame Rate: 10 ms
• Power Requirements: +5 V dc
• Operating Temperature: -30 to +65 °C
• Dimensions (W x L): 10.16 cm x 33.02 cm (or 17.8 cm x 33.02 cm variant)
• Indicators: Run, Fail, Status, Reset LEDs
• I/O Ports: Three IONet 10Base2 Ethernet ports, one RS-232C serial port
• Front Panel: Reset switch and LED indicators (1,2,4,8)
• Instruction Manual: GEH-6421
• Country of Origin: United States

Functional Overview

• The IS215VCMIH2C acts as the communication interface to the IONet network and I/O boards.
• It manages board IDs and terminal board assignments for all cards in the rack.
• This VCMI board supports local and distant I/O racks in simplex or TMR configurations.
• It features three IONet ports (R, S, T) for redundant communication channels.
• The board exchanges execution data with the main processor via application software.
• Front panel LEDs provide clear status: Run, Fail, Status, and numeric 1,2,4,8.
• A push-button reset switch allows quick manual system resets.
• This board is critical for system operation; we recommend keeping spares.

Installation & Environment

• Mount the IS215VCMIH2C in a standard 6U VME chassis.
• Ensure proper backplane connection for VME bus communication.
• Operate within -30 to +65 °C for reliable performance.
• Provide +5 V dc power supply with adequate current capacity.
• Connect IONet cables to the three 10Base2 ports (R, S, T).
• Use the RS-232C port for local diagnostic access.
• Secure all terminal board connections per GEH-6421 guidelines.
• Verify board ID settings before system startup.

Package Contents

• One GE IS215VCMIH2C VME Bus Master Controller Board
• Product documentation and quick start guide
• Standard anti-static packaging for safe transport
• No additional cables or mounting hardware included

Shipping & Logistics

• We ship via FedEx, UPS, or DHL for fast and reliable delivery.
• All orders dispatch within 5 business days.
• We maintain stock for immediate shipment.
• All units are brand new and original.
• We offer a 30-day return policy for unopened items.

Frequently Asked Questions (FAQ)

• Is the IS215VCMIH2C a new original part? Yes, we supply only brand new, original General Electric boards.
• What is the typical lead time? We ship within 5 business days via FedEx, UPS, or DHL.
• Does this board support TMR systems? Yes, the IS215VCMIH2C works in simplex and triple-redundant setups.
• What is the operating temperature range? The board operates from -30 to +65 °C.
• Can I get a manual for this board? The manual GEH-6421 is available online and in the package.
• What is the board's frame rate? The frame rate is 10 ms for fast loop updates.
• Do you accept returns? Yes, we accept returns within 30 days of delivery.
