DS200DTBBG1ABB GE Mark V Terminal Board Digital Connector Card

GE DS200DTBBG1ABB – Mark V Terminal Board Digital Connector Card

Key Technical Specifications

• Part Number: DS200DTBBG1ABB from General Electric.
• Series: Mark V – functional revision 1A.
• Terminal Blocks: Two blocks (TB1 and TB2) with terminals for 95 signal wires each.
• Total Signal Capacity: Up to 110 signal wires can connect to the terminal blocks.
• Connectors: Three 50-pin connectors with IDs JFF, JFG, and JFH.
• Additional Connectors: Bayonet connectors and five jumpers included.
• PCB Coating: Normal coating for standard industrial protection.
• Product Type: Terminal Board Digital Connector Card / Contact Input Expansion Termination Module.

Connector Configuration

• The three 40-pin connectors use IDs JFF, JFG, and JFH for clear identification.
• Record which 40-pin ribbon cable connects to each connector during installation.
• Connecting ribbon cables to the wrong connectors requires a drive shutdown and restart.
• Proper cable management prevents productivity loss and operator inconvenience.
• Compatible connectors include the JRR TCDA contact input connector.
• The JY 125 V DC DTBA board power connector also works with this board.
• The JRS/T connector typically remains unused in most configurations.

Terminal Block Wiring

• Terminal block TB1 and terminal block TB2 each hold terminals for 95 signal wires.
• Individual terminals are numbered sequentially on each terminal block.
• Identify a specific terminal using the block ID and terminal number (e.g., TB1 90, TB2 48).
• TB1 90 means terminal 90 on terminal block 1.
• TB2 48 means terminal 48 on terminal block 2.
• Document all signal wire connections to simplify future maintenance.

Installation Guidelines

• Power down the drive system completely before installing or replacing the board.
• Record the ribbon cable connections to JFF, JFG, and JFH before removal.
• Connect the 40-pin ribbon cables to the correct connectors during installation.
• Secure all terminal block wiring with proper torque specifications.
• Restart the drive and verify proper operation after board replacement.
• Incorrect cable connections require a full drive shutdown and rework.

Package Contents

• 1 x DS200DTBBG1ABB Terminal Board Digital Connector Card
• Anti-static packaging for safe transport
• Product documentation and installation guide

Shipping & Logistics

• We ship via FedEx, UPS, or DHL – tracking number provided within 24 hours.
• All items are new surplus stock, ready for immediate dispatch.
• Delivery within 5 business days after order confirmation.
• 30-day return policy applies for unopened and undamaged products.

Frequently Asked Questions

• Q: Is this board new or refurbished?
  A: We supply new surplus units in factory packaging, never used.
• Q: What is the typical lead time for delivery?
  A: We ship within 5 days after order placement, with express courier options available.
• Q: How many signal wires can this board handle?
  A: The DS200DTBBG1ABB supports up to 110 signal wires across two terminal blocks.
• Q: What are the connector IDs on this board?
  A: The three 40-pin connectors use IDs JFF, JFG, and JFH.
• Q: What happens if I connect ribbon cables to the wrong connectors?
  A: You must shut down the drive, move the cables to the correct connectors, and restart.
• Q: How do I identify specific terminals?
  A: Use the terminal block ID (TB1 or TB2) and the terminal number (e.g., TB1 90).
• Q: What voltage does the power connector use?
  A: The JY connector accepts 125 V DC for the DTBA board power.
• Q: Do you offer technical support for installation?
  A: Yes, our team provides application notes and wiring diagrams; contact us for detailed assistance.
