New NSv Probe Bently Nevada 330904-08-15-10-12-00

Product Overview: Bently Nevada 3300 NSv Proximity Probe

Product Identification & Configuration

• Part Number: 330904-08-15-10-12-00
• Model: 3300 NSv Proximity Probes
• Manufacturer: Bently Nevada
• Condition: New & Original in Factory Packing

Ordering Code Breakdown

• Model (330904): This denotes a 3300 NSv Probe with M8x1 thread and stainless steel armor.
• Unthreaded Length (-08): The probe has an 80 mm unthreaded section.
• Overall Case Length (-15): The total case length is 150 mm.
• Total Cable Length (-10): It is fitted with a 1.0 meter (39 inch) integrated cable.
• Connector Type (-12): Features a Miniature coaxial ClickLoc connector with FluidLoc cable.
• Agency Approval (-00): This configuration requires no specific agency approvals.

Technical Highlights

• Electrical Specs: Probe DC resistance is 4.2 ± 0.5 Ω. Cable resistance is 0.220 Ω/m (center) and 0.066 Ω/m (shield).
• Cable Data: Typical extension cable capacitance is 69.9 pF per meter.
• Field Wiring: Use 0.2 to 1.5 mm2 (16 to 24 AWG) shielded triad cable for connections.
• Wiring Length: Supports a maximum field wiring length of 305 meters (1,000 feet).
• Measurement Range: Offers a standard 1.5 mm (60 mils) linear range.
• Setup: The recommended gap setting is 1.0 mm (40 mils) for optimal operation.
• Sensitivity: The Incremental Scale Factor (ISF) is 7.87 V/mm ±12.5%/-20%.
• Accuracy: Deviation from Best Fit Line (DSL) is less than ±0.06 mm (2.3 mils).
• Frequency Response: Flat from 0 to 10 kHz with a full 305m cable run.

Frequently Asked Questions (FAQ)

• Q: What is the key feature of the "-12" connector suffix?
  A: The -12 suffix indicates a ClickLoc connector with FluidLoc cable, offering enhanced environmental sealing.
• Q: How does the 1.0m cable length affect installation?
  A: The 1.0 meter cable provides more flexibility for routing compared to the standard 0.5m version, often reducing the need for immediate extension cables.
• Q: Is this probe suitable for high-vibration environments?
  A: Yes, its 10 kHz frequency response and robust stainless steel armor make it ideal for capturing data in high-vibration machinery.
• Q: Do you guarantee this is an original Bently Nevada part?
  A: Absolutely. We supply only 100% new and original Bently Nevada products in sealed factory packaging.
• Q: Is part number 330904-08-15-10-12-00 in stock?
  A: Yes, this specific configuration is in stock and available for immediate order processing.
• Q: What are the shipping options and timelines?
  A: Orders ship within 5 business days via DHL, FedEx, or UPS. We offer a 30-day return policy.

Access comprehensive installation and calibration guidelines by downloading the full datasheet: 3300 XL NSv Proximity Transducer System Datasheet - 147385.
