330102-00-48-10-02-05 8 mm Proximity Probe | Bently Nevada

Bently Nevada 330102-00-48-10-02-05: 3300 XL 8 mm Proximity Probe

• Brand & Model: Bently Nevada – 330102-00-48-10-02-05 (3300 XL 8 mm Probe).
• Unthreaded Length Option: 00 = 0.0 inches.
• Overall Case Length Option: 48 = 4.8 inches.
• Total Length Option: 10 = 1.0 meter (3.3 feet).
• Connector & Cable Type: 02 = Miniature coaxial ClickLoc connector with standard cable.
• Agency Approval Option: 05 = CSA, ATEX, IECEx Approvals.
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 303 or 304 stainless steel (SST).

Key Technical Specifications

• Linear Range: 2 mm (80 mils) starting from 0.25 mm (10 mils) up to 2.3 mm (90 mils).
• Recommended Gap Setting (Radial Vibration): -9 Vdc at approx 1.27 mm (50 mils).
• Nominal DC Resistance (1.0 meter length): 7.59 ± 0.50 Ω (center to outer conductor).
• Field Wiring: Accepts 0.2 to 1.5 mm² (16 to 24 AWG) with 3-conductor shielded triad cable. Maximum length between sensor and monitor: 305 meters (1000 feet).
• Operating & Storage Temperature (Standard): -52°C to +177°C (-62°F to +350°F).
• Extended Temperature Probe Tip: -52°C to +218°C (-62°F to +425°F); cable/connector: -51°C to +260°C (-60°F to +500°F). Note: Exposing below –34°C (–30°F) may damage pressure seal.
• Relative Humidity Tolerance: Less than 3% change in Average Scale Factor (ASF) at 93% humidity per IEC 68-2-3 (up to 56 days).
• Probe Pressure Sealing: Uses Viton® O-ring; seals differential pressure between tip and case.
• Thread Engagement Limits: Probe case thread 3/8-24; maximum thread engagement length: 0.563 inches.
• Weight: 323 g/m (11.4 oz).

Hazardous Area Approvals & Safety

• Intrinsically Safe (ia): When installed with zener barriers (drawing 141092) or galvanic isolators. Class I, Zone 0: AEx/Ex ia IIC T5...T1 Ga; Class I, Groups A,B,C,D; Class II Groups E,F,G; Class III.
• Non-incendive (nA, ec): When per drawing 140979. Class I, Zone 2: AEx/Ex nA IIC T5…T1 Gc; Class I, Division 2, Groups A,B,C,D; also ec IIC T5…T1 Gc.

Installation & Mechanical Details

• Use 3/8-24 UNF thread for probe mounting.
• Do not exceed 0.563 inch thread engagement length.
• Keep probe cable away from extreme bends or crushing forces.
• Follow recommended gap setting of -9 Vdc for optimal radial vibration sensing.
• Ensure operating temperatures stay within -52°C to +177°C for standard probes.
• For extended temperature ranges, refer to tip and cable limits above.

Packaging & Delivery Information

• Packaging List: One 330102-00-48-10-02-05 probe assembly with ClickLoc connector and standard armored cable.
• Shipping Carriers: FedEx, UPS, DHL.
• Stock Status: Genuine new original – available in stock.
• Dispatch Time: Ships within 5 business days after order confirmation.
• Returns: 30 days return policy supported.

Frequently Asked Questions (FAQ)

• Q: Is the 330102-00-48-10-02-05 a genuine Bently Nevada product?
  A: Yes, we supply only brand new and original Bently Nevada probes. No refurbished or counterfeit items.
• Q: What is the linear measurement range of this 3300 XL 8 mm probe?
  A: It provides a linear range of 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
• Q: Can I use this probe with a 5-meter Proximitor sensor?
  A: No, the 1.0 meter length (option 10) works with standard Proximitor sensors. Use 330101 probes for 3-meter lengths. 5-meter probes require specific 5-meter Proximitor sensors.
• Q: What approvals does the 330102-00-48-10-02-05 carry?
  A: This model includes CSA, ATEX, and IECEx approvals (option 05).
• Q: What temperature range does it support?
  A: Standard operating range is -52°C to +177°C. Avoid temperatures below -34°C to protect the pressure seal.
• Q: How soon will you ship the probe?
  A: We ship within 5 days using DHL, FedEx, or UPS. Express delivery available.
• Q: What is the thread size and engagement limit?
  A: Thread size is 3/8-24 UNF, with a maximum engagement length of 0.563 inches.
• Q: Can I return the product if it doesn't meet my needs?
  A: Yes, we support a 30-day return policy for unused items in original packaging.
