2090-CFBM7DF-CDAF75 Allen-Bradley SpeedTec DIN Cable

Allen-Bradley 2090-CFBM7DF-CDAF75 Motor Feedback Cable

The 2090-CFBM7DF-CDAF75 is a long-length motor feedback cable from the 2090 Dual Power/Feedback series. This cable ensures precise signal transmission for incremental encoders.

Core Technical Specifications

• Brand & Series: Allen-Bradley 2090
• Model Number: 2090-CFBM7DF-CDAF75
• Cable Function: Motor Feedback Only
• Encoder Type: Incremental Encoder
• Drive End Connector: Flying-Lead (Wire Ends)
• Motor End Connector: SpeedTec DIN Connector
• Flexibility Rating: Continuous-Flex Design
• Cable Length: 75 Meters
• Conductor Gauge: 20 AWG
• Shielding: ≥85% Braided Shield
• Operating Voltage: 30V AC/DC max
• Operating Temperature: -20°C to +80°C
• Flex Life: ≥5 million cycles
• Min. Bending Radius: 10x cable diameter (in motion)

Cable Features & Application

• Transmits incremental encoder signals over a long 75-meter distance.
• SpeedTec DIN connector ensures a reliable motor-side connection.
• Flying-lead drive end allows for custom termination to control cabinets.
• Continuous-flex construction is built for use in cable carriers and tracks.
• High-grade shielding protects signal integrity in electrically noisy environments.
• 75-meter length is ideal for large gantry systems and extended machinery.

Installation & Compatibility Notes

• This cable is designed for Allen-Bradley MP-Series and 2090-series servo systems.
• Match the SpeedTec DIN connector to the encoder port on your servo motor.
• Properly terminate and ground the shielding at the drive end to prevent EMI.
• When used in a cable carrier, maintain the minimum bending radius.
• Route the cable away from power lines and motor drives to minimize interference.

Packaging & Shipping Details

• The 2090-CFBM7DF-CDAF75 cable is supplied on a protective reel.
• Each cable is a continuous 75-meter length, factory-tested for performance.
• International shipping via FedEx, UPS, and DHL is available.
• Tracking information is provided immediately after dispatch.

Frequently Asked Questions

• What is the maximum length of this cable? This specific model is 75 meters long.
• What type of encoder does it support? It is designed for incremental encoder feedback.
• How is the drive end connected? It has flying leads (bare wires) for termination to terminal blocks.
• Is this cable suitable for moving applications? Yes, its continuous-flex design is for dynamic use.
• What is the voltage rating? It is rated for a maximum of 30V AC/DC signal transmission.

For system compatibility or to order the 2090-CFBM7DF-CDAF75, contact our team.

Contact: Email sales@nex-auto.com or WhatsApp +86 153 9242 9628.

Partner: NexAuto Technology Limited
