TSXAEY810 Schneider Electric Analog Input Module

TSXAEY810 Analog Input Module by Schneider Electric for Modicon Premium

Key Technical Specifications

• Brand: Schneider Electric
• Model: TSXAEY810
• Category: Analog Input Module
• Series: Modicon Premium
• Number of Inputs: 8 isolated analog channels
• Input Types: 0–20 mA, 4–20 mA, ±10 V, 0–10 V, 0–5 V, 1–5 V
• Resolution: 16 bits
• Measurement Error: 0.12% to 0.305% of full scale
• Read Cycle Time: 29.7 ms nominal
• Isolation: 1000 Vrms between channels and bus
• Temperature Range: 0°C to 60°C operating
• Anti-interference: Isolated channels reduce electrical noise

Installation Guide

• Mount the module on a standard rack for Modicon Premium systems.
• Connect field wiring to the SUB-D 25 connector on the front.
• Match each input type to your sensor signal range.
• Use shielded cables to maintain signal integrity in noisy areas.
• Verify all connections before you power the system.

Package Contents

• One TSXAEY810 analog input module
• One SUB-D 25 connector
• One installation leaflet with wiring details

Shipping and Returns

• We ship within 5 days after we confirm your order.
• We use FedEx, UPS, and DHL for fast delivery.
• You can return the product within 30 days for a refund.

Frequently Asked Questions

• Q: How many analog inputs does the TSXAEY810 have?
  A: It provides 8 low-level isolated analog input channels.
• Q: What input signal types does this module support?
  A: It supports 0–20 mA, 4–20 mA, ±10 V, 0–10 V, 0–5 V, and 1–5 V.
• Q: What is the resolution of the TSXAEY810?
  A: The module offers 16-bit analog-to-digital conversion.
• Q: What is the operating temperature range?
  A: It works from 0°C to 60°C in industrial environments.
• Q: Is the product brand new and original?
  A: Yes, we supply brand new original modules from Schneider Electric.
• Q: How fast do you ship?
  A: We ship within 5 days using DHL, FedEx, or UPS.
• Q: Can I return the module if it does not fit my system?
  A: Yes, you can return it within 30 days for a refund.
