TC-IXL062 Honeywell Thermocouple Input Module 6-Point

Honeywell TC-IXL062 Thermocouple Input Module — 6-Point Analog Input

Key Technical Specifications

• Brand: Honeywell
• Model: TC-IXL062
• Category: Thermocouple Input Module
• Number of Points: 6 channels plus 2 cold junction channels
• Nominal Input Voltage Ranges: -12 mV to +78 mV; -12 mV to +30 mV (high resolution)
• Supported Thermocouple Types: B, E, J, K, R, S, T, N, C, D, L (see Note-1)
• Resolution: 16 bits (1.4 µV typical); 0.70 µV on high resolution range
• Accuracy (-12 mV to +78 mV Range): 0.1% FSR ±90 µV at 25℃
• Accuracy (-12 mV to +30 mV Range): 0.1% FSR ±42 µV at 25℃
• Accuracy (Cold Junction Sensor): Local CJ sensor (TB) and remote CJ sensor (RTP) error ±0.3℃
• Common Mode Rejection: 160 dB min. tested @ 600 VAC, 60 Hz, 100 Ω imbalance
• Module Update Rate for All Channels: 50 milliseconds
• Settling Time to 5% of Full Scale: Less than 80 milliseconds
• Open Circuit Detection: Open TC detection time 2 seconds typical; upscale reading
• Channel Bandwidth: 0 to 15 Hz (-3 db)
• Normal Mode Noise Rejection: 60 dB @ 60 Hz
• RFI Immunity: TBD
• Overvoltage Capability: 120 VAC/VDC continuous at 25℃
• Input Offset Drift with Temperature: 0.5 µV/℃ typical
• Gain Drift with Temperature: 25 ppm/℃ (2.3 µV for -12 mV to +78 mV range, 1.1 µV for -12 mV to +30 mV range)
• Power Dissipation: 4.3 W max
• Backplane Current: See Module Power Consumption Data, page 46
• Spare CJR Thermistor Model Number: TC-CJRT02 (this module uses 2 CJRs)
• Isolation Voltage — Channel to Channel: 250 V, 100% tested at 1900 V for 2 s
• Isolation Voltage — User to System: 250 V, 100% tested at 1900 V for 2 s
• Connection Terminal Blocks: TC-TBNH, 20-position terminal block
• Input Impedance: Greater than 10 MΩ
• Note-1: D and L TC types are not supported for releases prior to Experion PKS R210 patch 10

Performance and Environmental Durability

• The module achieves 0.1% FSR accuracy at 25℃ across both input voltage ranges.
• Each channel provides isolation tested at 1900 V for two seconds between channel and system.
• The TC-IXL062 survives continuous 120 VAC/VDC overvoltage at 25℃ without damage.
• Common mode rejection reaches 160 dB minimum at 600 VAC, 60 Hz, and 100 Ω imbalance.
• Gain drift stays at 25 ppm/℃ typical, improving stability over the earlier TC-IXL061 design.
• Two cold junction channels plus remote CJ sensor support keep reference compensation within ±0.3℃.

Installation Guide

• Mount the module in a Honeywell I/O rack that supports the TC-IXL062 thermocouple input series.
• Use the TC-TBNH 20-position terminal block for field wiring and secure each connection firmly.
• Rewire the terminal block when upgrading from the older TC-IXL061 module to this unit.
• Install a new pre-wire cable when your system uses an RTP (Remote Termination Panel).
• Fit two TC-CJRT02 thermistors because this module relies on two cold junction references.
• Route thermocouple wiring away from high-voltage lines to preserve noise rejection and accuracy.
• Confirm your Experion PKS release supports D and L thermocouple types before configuration.

Package List

• 1 × Honeywell TC-IXL062 Thermocouple Input Module
• 1 × TC-TBNH 20-position terminal block
• 1 × Anti-static protective bag
• 1 × Protective foam packaging

Shipping and Support

• We ship with FedEx, UPS, and DHL to most international destinations.
• Our team dispatches in-stock items within 5 days after order confirmation.
• You may request a return within 30 days under our standard return policy.
• All units are brand new and original from the manufacturer.

FAQ

• Q: Which module does the TC-IXL062 replace?
  A: It replaces the TC-IXL061 and requires terminal block rewiring during upgrade.
• Q: How many channels does this module provide?
  A: It offers 6 thermocouple channels plus 2 cold junction channels.
• Q: Which thermocouple types does the TC-IXL062 support?
  A: It supports B, E, J, K, R, S, T, N, C, D, and L types.
• Q: What input voltage ranges does the module accept?
  A: It accepts -12 mV to +78 mV and a high resolution -12 mV to +30 mV range.
• Q: What resolution does the TC-IXL062 deliver?
  A: It delivers 16 bits (1.4 µV typical) and 0.70 µV on the high resolution range.
• Q: How fast does the module update all channels?
  A: The module updates all channels in 50 milliseconds.
• Q: What is the open thermocouple detection time?
  A: It detects an open thermocouple in 2 seconds typical with an upscale reading.
• Q: What is the input impedance?
  A: Input impedance is greater than 10 MΩ.
• Q: Which spare thermistor should I order?
  A: Order the TC-CJRT02 thermistor, and note this module uses two CJRs.
• Q: Are D and L thermocouple types always supported?
  A: They need Experion PKS R210 patch 10 or later releases.
