IS200DSPXH2CAA General Electric Digital Signal Processor

IS200DSPXH2CAA Digital Signal Processor Control Board by GE Industrial Systems

Technical Specifications

• Brand: General Electric (GE Industrial Systems).
• Model Number: IS200DSPXH2CAA.
• Part Number: IS200DSPXH2C.
• Series: Innovation Series and EX2100.
• Instruction Manual: GEI-100267A / GEI-100267B.
• Functional Abbreviation: DSPX (Digital Signal Processor Control).
• Processor Speed: 60 MHz digital signal processor.
• LED Indicators: One red fault LED and one green status LED.
• I/O Connectors: P1 backplane, P5 DSP emulator, P6 engineering monitor.
• Number of Channels: 12 channels.
• Voltage Range: 14 to 32 V dc.
• Max Load Current: 125 V dc.
• Outputs: 24 V dc.
• Maximum Lead Resistance: 15 Ω.
• Mounting: DIN-rail mounting.
• Operating Temperature: -30 to 65°C.
• Size: 15.9 cm high x 17.8 cm.
• Weight: 2 lbs.
• Country of Origin: United States.
• Repair Time: 3 to 7 days.
• Availability: In Stock.

Hardware Features and Onboard Components

• The IS200DSPXH2CAA includes a high-performance DSP with an ASIC for custom logic functions.
• It provides four external interrupts during normal operation: INT0 (stack overflow), INT1 (inner loop load pulse), INT2 and INT3 (configurable inputs).
• The front faceplate helps secure the board inside the rack system.
• This faceplate holds the two LED indicators and two of the four I/O ports.
• The board number and General Electric logo appear clearly on the faceplate.
• Onboard components include 16 integrated circuits, transistors, resistor networks, capacitors, and diodes.
• A vertical pin connector sits adjacent to the front I/O ports.
• The rear edge features a backplane connector with a complex pin configuration.
• This board uses surface mount technology for compact construction.

Memory and Firmware

• The IS200DSPXH2CAA uses multiple memory types: FLASH, RAM, NVRAM, and add-only memory for revision identification.
• Onboard firmware includes a boot loader, application code, and configuration parameters.
• Do not reload or modify the boot loader in the field.
• FLASH memory stores DSP boot images, executable code, and system history records.
• RAM provides temporary storage for code execution and data buffers.
• NVRAM retains critical configuration parameters across power cycles.

Frequently Asked Questions (FAQ)

• Q: Is the IS200DSPXH2CAA brand new and original?
  A: Yes, we supply only brand new and original units from authorized sources.
• Q: What turbine systems is this board compatible with?
  A: The board works with GE gas, steam, and wind turbines within the Mark VI series.
• Q: What memory types does this board include?
  A: It includes FLASH, RAM, NVRAM, and add-only memory for revision identification.
• Q: How many I/O connectors does the board have?
  A: The board has three I/O connectors: P1 backplane, P5 DSP emulator, and P6 engineering monitor.
• Q: What do the two LEDs indicate?
  A: The red LED shows a fault condition. The green LED indicates status and normal operation.
• Q: What happens during a watchdog timer timeout?
  A: A watchdog timeout generates a hard reset to maintain system safety.
• Q: Do you have the IS200DSPXH2CAA in stock?
  A: Yes, we have this model in stock and ready to ship.
• Q: What is the typical repair time for this board?
  A: Standard repair takes 3 to 7 days.

For any inquiries, please contact our sales team at sales@nex-auto.com or +86 153 9242 9628 via WhatsApp. Partner NexAuto Technology Limited offers full support for GE automation products.
