Bently Nevada 330103-00-05-20-02-00 8mm Proximity Probe

Bently Nevada 3300 XL 8mm Proximity Probe – 330103-00-05-20-02-00

Core Technical Specifications

• Manufacturer: Bently Nevada – model 330103-00-05-20-02-00 belongs to the 3300 XL Series.
• Thread & Cable: M10 x 1 thread, no armor, with a 2.0 meter standard cable and miniature coaxial ClickLoc connector.
• Unthreaded Length: 00 mm; Overall Case Length: 50 mm for compact installations.
• DC Resistance: Nominal RPROBE is 7.88 ± 0.50 Ω between center and outer conductors.
• Linear Range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils), output -1 to –17 Vdc.
• Gap Setting: Set to -9 Vdc (approximately 1.27 mm / 50 mils) for optimal radial vibration sensing.
• Temperature Range: Standard probe operates from -52°C to +177°C (-62°F to +350°F).
• Extended Temperature: Tip reaches +218°C (+425°F); cable and connector up to +260°C (+500°F).
• Humidity Tolerance: Less than 3% ASF change after 56 days at 93% RH per IEC 68-2-3.

Frequently Asked Questions (FAQ)

• Q: Does this probe work with all 3300 XL Proximitor Sensors?
  A: Yes, the 330103-00-05-20-02-00 is fully compatible with the 3300 XL Proximitor Sensor series.
• Q: What is the exact linear measurement range?
  A: The linear range is 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
• Q: Can I use this probe above +177°C?
  A: The standard probe handles up to +177°C; the extended tip option supports +218°C.
• Q: What is the recommended gap for radial vibration?
  A: Set the air gap to -9 Vdc, which corresponds to about 1.27 mm (50 mils).
• Q: What cable type should I use for field wiring?
  A: Use 3-conductor shielded triad cable, 16–24 AWG, up to 305 meters long.
• Q: Is this probe certified for hazardous areas?
  A: Yes, with proper barriers it meets Class I, Zone 0 (ia) and Zone 2 (nA/ec) requirements.
