S30A-7111DP SICK S3000 PROFINET Safety Laser Scanner 7m Range

S30A-7111DP SICK S3000 PROFINET IO Safety Laser Scanner – 7 m Protective Field, 190° Scan Angle

Key Technical Specifications

• Brand: SICK Sensors
• Model: S30A-7111DP
• Series: S3000 PROFINET IO Professional
• Protective field range: 7 m
• Warning field range: 49 m (20 m at 20% reflectivity)
• Distance measuring range: 49 m
• Scanning angle: 190°
• Resolution (configurable): 30 mm, 40 mm, 50 mm, 70 mm, 150 mm
• Angular resolution: 0.5°, 0.25° (depending on range and resolution)
• Response time: 60 ms
• Protective field supplement: 100 mm
• Number of field sets: 8
• Number of fields: 16
• Number of monitoring cases: 16
• Number of simultaneously monitored protective fields: 2
• Type of field set: Dual field sets
• Multiple samplings: 2 to 16, configurable
• Delay of automatic reset: 120 ms to 4,920 ms, configurable

Safety-Related Parameters

• Type: Type 3 (IEC 61496)
• Safety integrity level: SIL 2 (IEC 61508)
• Category: Category 3 (EN ISO 13849)
• Performance level: PL d (EN ISO 13849)
• PFHD: 8.0 x 10^-8
• Mission time (TM): 20 years (EN ISO 13849)
• Safe state in the event of a fault: The safety-related data is logic 0.

Functions & Interfaces

• Restart interlock: Yes
• Multiple sampling: Yes
• Monitoring case switching: Yes
• Simultaneous monitoring: Yes
• Static protective field switching: Yes
• Contour as a reference: Yes
• Integrated configuration memory: Yes
• Measured data output: Via RS-422
• Bus connection: Copper conductor (2 female connectors for RJ-45 push-pull plug)
• Supply connection: System plug with or without connecting cable
• Configuration and diagnostics interface: RS-232
• Transmission rate: 9.6 kBaud, 19.2 kBaud, 38.4 kBaud
• Fieldbus: PROFINET PROFIsafe
• Conformance: Conformance Class B
• Cycle time: 4, 8, 16, 32 ms, etc.

Mechanical & Environmental Data

• Dimensions (W x H x D): 155 mm x 185 mm x 160 mm
• Weight: 3.3 kg
• Housing material: Aluminum die cast
• Housing color: RAL 1021 (yellow)
• Front screen material: Polycarbonate
• Front screen surface finish: Outside with scratch-resistant coating
• Enclosure rating: IP65 (EN 60529)
• Ambient operating temperature: –10 °C to +50 °C
• Storage temperature: –25 °C to +50 °C
• Vibration resistance: IEC 60068-2-6, IEC 60068-2-64, IEC 60721-3-5, IEC TR 60721-4-5, IEC 61496-3
• Shock resistance: IEC 60068-2-27, IEC 60721-3-5, IEC TR 60721-4-5, IEC 61496-3
• Continuous shock: 50 m/s², 11 ms; 100 m/s², 16 ms

Installation Guide

• Mount the scanner indoors on a stable surface using the aluminum die cast housing.
• Connect the device only within a network that has a corresponding PROFINET controller.
• Use the system plug with or without connecting cable for the supply connection.
• Align the scanning plane to cover the hazardous area up to 7 m.
• Configure resolution, multiple samplings, and monitoring cases before operation.
• Ensure the IP65 rating by sealing all connections properly.
• Verify the ambient operating temperature stays between –10 °C and +50 °C.

Package List

• 1 x SICK S30A-7111DP Safety Laser Scanner
• 1 x Sensor head without system plug
• 1 x Quick start guide

Shipping & Returns

• We ship via FedEx, UPS, and DHL.
• We dispatch your order within 5 days.
• We offer a 30-day return policy.
• All items are brand new and original.

FAQ

• Q: What is the protective field range of this SICK S3000 scanner?
  A: The S30A-7111DP offers a protective field range of 7 m.
• Q: What is the warning field range?
  A: The warning field range is 49 m (20 m at 20% reflectivity).
• Q: What is the scanning angle?
  A: The scanning angle is 190°.
• Q: What resolution options does this scanner provide?
  A: You can configure 30 mm, 40 mm, 50 mm, 70 mm, or 150 mm.
• Q: What is the response time?
  A: The response time is 60 ms.
• Q: What safety integrity level does it meet?
  A: It meets SIL 2 (IEC 61508) and PL d (EN ISO 13849).
• Q: What is the enclosure rating?
  A: It has an IP65 rating (EN 60529).
• Q: What is the operating temperature range?
  A: The ambient operating temperature range is –10 °C to +50 °C.
• Q: Does this scanner have local inputs or outputs?
  A: No, it operates only in a network with a corresponding controller.
• Q: What fieldbus does it use?
  A: It uses PROFINET PROFIsafe.
• Q: How fast do you ship?
  A: We ship within 5 days via FedEx, UPS, or DHL.
• Q: Can I return the product?
  A: Yes, we support 30-day returns.
