Bently Nevada 200355-02-00-00 Accelerometer | 100mV/g

Bently Nevada 200355-02-00-00 Accelerometer Technical Overview

Complete Technical Specifications for 200355-02-00-00

• Full Model Configuration: The Bently Nevada 200355-02-00-00 features a #28 to M8x1.25 Beryllium Copper mounting stud. The "00" tolerance code indicates 100 mV/g ±20% sensitivity. The "00" approvals code means this unit carries no intrinsic safety certifications.
• Measurement Capabilities: This 200355-02-00-00 accelerometer operates across a frequency range of 30 to 600,000 CPM (0.5 to 10,000 Hz). It measures vibration up to ±50 g peak. The resonant frequency reaches 1,500 kCPM (25 kHz) for excellent high-frequency response.
• Electrical Parameters: You must provide 18–28 VDC excitation at 2–20 mA. The output bias voltage ranges from 8 to 12 VDC. Output impedance measures less than 150 Ohms for signal integrity.
• Noise Performance: The Bently Nevada 200355-02-00-00 maintains broadband noise of only 350 µg from 1–10 kHz. Transverse sensitivity stays below 7%. These low noise floors ensure reliable vibration analysis.
• Environmental Specifications: This sensor operates in temperatures from -54°C to +121°C. It survives 5,000 g peak shock events. The design handles 100% condensing humidity without performance degradation.
• Mechanical Characteristics: The discharge time constant meets or exceeds 0.3 seconds. This allows quick settling after power application. The rugged housing protects internal components from contamination.

Frequently Asked Questions About 200355-02-00-00

• What do the numbers in 200355-02-00-00 represent?
  The 200355-02-00-00 breaks down as series (200355), mounting stud type (02 = #28 to M8x1.25 BeCu), tolerance (00 = 100 mV/g ±20%), and approvals (00 = none). This coding system helps you select the exact configuration needed.
• Can I use this accelerometer in hazardous locations?
  The 200355-02-00-00 with "00" approvals lacks hazardous area certification. You must verify area classifications before installation. Consider Bently Nevada models with appropriate approvals codes for explosive environments.
• What tools do I need for installation?
  You need a torque wrench and appropriate socket for the 200355-02-00-00 mounting stud. Surface preparation requires a fine file or lapping plate. Contact cleaner ensures a contamination-free mounting interface.
• How does temperature affect the 200355-02-00-00 performance?
  The 200355-02-00-00 maintains specified performance across -54°C to +121°C. Sensitivity changes remain minimal within this range. The Beryllium Copper stud helps match thermal expansion rates.
• What is the typical lead time for this model?
  We maintain 200355-02-00-00 inventory for immediate shipment. Most orders process within 24 hours. International delivery via DHL, FedEx, or UPS typically takes 3-5 business days.

Download the complete Bently Nevada 200355-02-00-00 technical datasheet here: 200350 and 200355 Accelerometers PDF
