330901-00-32-05-02-05 NSv Sensor 11kHz 0.01mm Bently Nevada

330901-00-32-05-02-05 NSv Proximity Probe – 8 mm Precision Sensor

Technical Specifications & Key Features

• Brand: Bently Nevada · Model: 330901-00-32-05-02-05 (NSv series)
• Tip diameter: 8 mm – standard 8 mm probe size for easy installation
• Maximum pressure rating: 500 kPa for sealed environments
• Cable pull strength: 150 N – rugged against mechanical stress
• Frequency response: captures dynamic events up to 11 kHz
• Resolution: 0.01 mm for precise displacement measurements
• Sensitivity drift: 0.1 % per month – excellent long-term stability
• Warm-up time: 2 seconds – ready for measurement almost instantly
• Overall accuracy: within ±1 % of full scale over operating conditions
• Operating temperature: -52 °C to +177 °C for extreme environments
• Cable: 75 Ω FEP coax, 0.5 m length (suffix -05), outer diameter 3.8 mm
• DC resistance (0.5 m cable): 4.0 Ω ±0.5 Ω
• Connector: Mini coax ClickLoc type (-02 suffix) with built-in protector
• Connector torque: max 7.3 N·m, recommended 5.1 N·m for safe installation
• Maximum thread engagement: 0.375 in – prevents mechanical bottoming
• Case length: 3.2 in (-32 suffix) with no unthreaded section (-00)
• Weight: approx. 24 g – lightweight design
• Sealing: Built-in Viton O-ring provides reliable pressure sealing
• Agency approvals: Multiple international approvals included (suffix -05)

Download Full Datasheet

Datasheet: 3300 XL NSv Proximity Transducer System Datasheet - 147385 (PDF)

Frequently Asked Questions (FAQ)

• Q: Is the 330901-00-32-05-02-05 a brand-new original part?
  A: Yes, we supply only genuine new Bently Nevada probes, directly sourced from authorized channels.
• Q: What is the frequency response of this probe?
  A: The 330901-00-32-05-02-05 offers an 11 kHz bandwidth for dynamic measurements.
• Q: Can this probe withstand high pressure?
  A: Yes, it features a Viton O-ring seal rated for 500 kPa maximum pressure.
• Q: How fast does this sensor warm up?
  A: It requires only 2 seconds warm-up time before taking accurate readings.
• Q: What is the resolution of this model?
  A: It provides 0.01 mm resolution for fine displacement measurements.
• Q: Do you have the item in stock, and how soon can you ship?
  A: Yes, we maintain stock for the 330901-00-32-05-02-05. We ship within 5 days after order confirmation.
• Q: Which couriers do you use for delivery?
  A: We ship via FedEx, UPS, or DHL – you can choose your preferred express service at checkout.
• Q: What is your return policy?
  A: We offer a 30-day return window for this item, provided it remains in new and unused condition.
• Q: What approvals does the "-05" suffix include?
  A: The -05 suffix indicates the probe carries multiple international agency approvals for global use.
