330174-00-06-10-12-00 Bently Nevada Proximity Sensor 60mm

Bently Nevada 330174-00-06-10-12-00 – Armored 5mm Proximity Probe for Harsh Environments

Key Technical Specifications

• Manufacturer: Bently Nevada, part of the 3300 5mm transducer family.
• Product No.: 330174-00-06-10-12-00 with M8 x 1 thread and armor protection.
• Case Length: 60 mm stainless steel construction for robust performance.
• Total Cable Length: 1.0 meter (3.3 feet) with miniature coaxial ClickLoc connector.
• Cable Type: FluidLoc cable with 75 Ω triaxial, FEP insulated design.
• Tip Material: Polyphenylene sulfide (PPS) for excellent chemical resistance.
• Case Material: AISI 304 stainless steel (SST) for maximum durability.
• Operating Voltage: Accepts -17.5 Vdc to -26 Vdc with less than 2 mV supply sensitivity.
• Current Consumption: 12 mA maximum for efficient power usage.
• Output Resistance: 50 Ω ensuring excellent signal integrity.
• DC Resistance (1m): 7.59 ± 0.50 Ω meeting strict factory calibration standards.
• Country of Origin: Made in U.S.A. with Certificate of Origin available.

Mechanical Specifications

• Tensile Strength: 222 N (50 lbf) for reliable cable pull resistance.
• Connector Material: Gold-plated brass or beryllium copper for corrosion resistance.
• Case Torque: 5.1 N·m (45 in·lb) standard, maximum 7.3 N·m (65 in·lb).
• Cable Bend Radius: 25.4 mm (1.0 in) for flexible installation routing.
• Unthreaded Length: 0 mm providing full thread engagement for mounting.
• Weight: 0.323 Kg light enough for easy handling during installation.

Frequently Asked Questions (FAQ)

• Is this proximity probe brand new and original? Yes, we supply only new original Bently Nevada 330174-00-06-10-12-00 units.
• What is your stock availability for this model? We have in stock the 330174-00-06-10-12-00 ready for immediate dispatch.
• How fast can you ship the probe? We ship within 5 days after order confirmation.
• Which logistics partners do you use? We ship via DHL, FedEx, or UPS worldwide.
• What is the difference between this and the standard probe? This model features armored FluidLoc cable and PPS tip for extra durability.
• What is the operating voltage range? It requires -17.5 Vdc to -26 Vdc as specified in the datasheet.
• What materials contact the process? The tip uses PPS and the case uses AISI 304 stainless steel.
• Do you accept returns if I order the wrong part? Yes, we support 30-day returns for eligible items.
• Can I get the Certificate of Origin? Yes, available upon request with your order.
• Can I download the full datasheet? Absolutely, we provide a PDF below for the 3300 5mm system.

Download the official PDF guide: 3300 5 mm Transducer System Datasheet - 172036 (email this link to your engineering team).
