330174-00-05-10-12-00 Bently Nevada Proximity Probe 50 mm Case

Bently Nevada 330174-00-05-10-12-00 5mm Armored Proximity Probe Overview

Precision Engineering and Technical Specifications

• Brand & Model: This Bently Nevada 330174-00-05-10-12-00 includes a 1.0 m armored FluidLoc cable with a miniature coaxial ClickLoc connector. The probe uses durable Polyphenylene sulfide (PPS) tip material.
• Electrical Performance: The system delivers an output resistance of 50 Ω and consumes only 12 mA maximum current. It provides a precise probe DC resistance of 7.59 ± 0.50 Ω for the 1.0 m length.
• Environmental Tolerance: This armored probe operates reliably in extreme temperatures from -35°C to +177°C (-31°F to +351°F). Its AISI 304 stainless steel case resists corrosion effectively.
• Mechanical Durability: The probe withstands tensile strength of 222 N (50 lbf) at critical connection points. We recommend a probe case torque of 5.1 N·m (45 in·lb) and a maximum of 7.3 N·m (65 in·lb).
• Connector Specifications: Gold-plated brass or beryllium copper ensures excellent signal conductivity. Apply connector torque between 0.565 N·m and 0.85 N·m for optimal performance.
• Installation Guidelines: Maintain a minimum cable bend radius of 25.4 mm (1.0 in) during routing. This protects the FluidLoc cable integrity over time.

Frequently Asked Questions (FAQ)

• Q: What is the case length of the Bently Nevada 330174-00-05-10-12-00?
  A: This model features a 50 mm overall case length. The 00 unthreaded length option provides a standard mounting profile.
• Q: What makes this probe armored compared to standard versions?
  A: The Bently Nevada 330174-00-05-10-12-00 uses FluidLoc cable with enhanced protection. This armor resists abrasion and chemical exposure in harsh industrial environments.
• Q: What is the total cable length on this configuration?
  A: This specific probe includes a 1.0 metre (3.3 feet) armored cable. The 10 option in the part number specifies this standard length.
• Q: Does this probe require agency approvals for general use?
  A: The 00 agency approval option means this model does not require specific certifications. It suits general industrial monitoring applications perfectly.
• Q: Is the technical datasheet available for download?
  A: Yes, we encourage you to download the full 3300 5 mm Transducer System Datasheet for complete specifications. Find the link in the description above.

Download the official PDF datasheet here: 3300 5 mm Transducer System Datasheet - 172036 (PDF).
