Bently Nevada 330104-08-11-10-02-CN 3300 XL 8 mm Proximity Probe

Core Technical Specifications

• Manufacturer & Model: Bently Nevada 330104-08-11-10-02-CN (3300 XL 8 mm Probe).
• Linear Range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils) from the target.
• Output Voltage: Approximately –1 to –17 Vdc across the full linear range.
• Recommended Gap (Radial Vibration): -9 Vdc, which corresponds to about 1.27 mm (50 mils).
• Probe Length & Resistance: 1.0 meter length with a nominal DC resistance of 7.59 ± 0.50 Ω.
• Thread & Engagement: M10 x 1 thread with a maximum engagement of 15 mm.
• Operating Temperature (Standard): -52°C to +177°C (-62°F to +350°F).
• Extended Temperature Tip: Up to +218°C (+425°F) for the tip; cable and connector up to +260°C (+500°F).
• Relative Humidity: Less than 3% change in ASF after 56 days at 93% humidity (IEC 68-2-3).
• Sealing Material: Viton® O-ring for differential pressure sealing between the tip and case.

Environmental & Installation Details

• Probe Materials: Polyphenylene sulfide (PPS) tip and AISI 303/304 stainless steel case.
• Pressure Seal Caution: The probe uses a Viton® O-ring; we do not pressure test each unit before shipping.
• Field Wiring: Use 0.2 to 1.5 mm² (16 to 24 AWG) shielded triad cable, with a max length of 305 m (1,000 ft) between sensor and monitor.
• Frequency Response: Longer field wiring lengths affect high-frequency rolloff – see the signal rolloff graphs for details.
• Intrinsic Safety: Suitable for Class I, Zone 0 (AEx/Ex ia IIC T5…T1 Ga) with zener barriers or galvanic isolators.
• Non-incendive Use: Compliant with Class I, Division 2 (AEx/Ex nA IIC T5…T1 Gc) per drawing 140979.
• Temperature Class (Probe Only): T1 at +232°C, T2 at +177°C, T3 at +120°C, T4 at +80°C, T5 at +40°C (ambient).

Mechanical & Electrical Characteristics

• Probe Weight: 323 g/m (11.4 oz per meter).
• Connector Type: Miniature coaxial ClickLoc connector with standard cable.
• Agency Approval: Option CN provides country-specific approvals for this model.
• Unthreaded Length: Option 08 gives an 80 mm unthreaded section.
• Overall Case Length: Option 11 sets the case length to 110 mm.
• Total Length: Option 10 delivers a 1.0 meter (3.3 feet) total probe length.
• Probe Case Torque: Recommended 11.2 N•m (100 in•lbf); maximum rated 33.9 N•m (300 in•lbf).

Packaging & Delivery Information

• Packaging Contents: One Bently Nevada 330104-08-11-10-02-CN probe with integrated cable and connector.
• Shipping Methods: We use FedEx, UPS, and DHL for fast and reliable delivery.
• Stock Status: We have this item in stock and ready for immediate dispatch.
• Dispatch Time: We ship within 5 business days after order confirmation.
• Return Policy: We support a 30-day return window for this product.

Frequently Asked Questions (FAQ)

• Is this probe new and original? Yes, we supply 100% new and genuine Bently Nevada 330104-08-11-10-02-CN probes.
• What is the recommended gap for radial vibration? Set the gap to -9 Vdc, approximately 1.27 mm (50 mils).
• Can I use this probe in high humidity? Yes, it maintains less than 3% scale factor change after 56 days at 93% humidity.
• What is the maximum field wiring length? You can use up to 305 meters (1,000 feet) between the sensor and monitor.
• Does the probe seal pressure? The Viton® O-ring seals differential pressure, but we do not test each unit before shipping.
• What temperature range does the cable support? The cable and connector operate from -51°C to +260°C (-60°F to +500°F).
• How long does shipping take? We dispatch within 5 days and use FedEx, UPS, or DHL for fast delivery.
• Can I return the probe if it does not fit my application? Yes, we offer a 30-day return policy for this model.
