330102-27-46-10-02-05 Bently Nevada 3300 XL Probe

Bently Nevada 330102-27-46-10-02-05: 3300 XL 8 mm Proximity Probe

• Linear Range: 2 mm (80 mils). The range starts at 0.25 mm (10 mils) from the target. It extends from 0.25 to 2.3 mm (10 to 90 mils). This corresponds to approximately –1 to –17 Vdc.
• Recommended Gap Setting for Radial Vibration: -9 Vdc. This equals approximately 1.27 mm (50 mils).
• Nominal Probe DC Resistance (RPROBE): 7.59 ± 0.50 Ω for a 1.0 meter probe length. This measurement applies from center conductor to outer conductor.
• Field Wiring: Use 0.2 to 1.5 mm² (16 to 24 AWG) wiring. We recommend 3 conductor shielded triad cable with tinned wiring. The maximum length between the 3300 XL Proximitor Sensor and the monitor is 305 meters (1,000 feet).

Environmental and Mechanical Specifications

• Probe Temperature Range (Standard): -52°C to +177°C (-62°F to +350°F) for operating and storage. Exposing the probe below –34˚C (-30˚F) may cause premature pressure seal failure.
• Probe Relative Humidity: Less than a 3% change in Average Scale Factor (ASF) at 93% humidity. This complies with IEC standard 68 2 3 for up to 56 days.
• Probe Pressure Design: The 3300 XL 8 mm probe seals differential pressure between tip and case. The seal uses a Viton® O-ring. Bently Nevada does not pressure test probes before shipment.
• Thread Engagement Limits: The probe case thread is 3/8-24. The maximum thread engagement length is 0.563 inches.
• Probe Weight: 323 g/m (11.4 oz).

Frequently Asked Questions (FAQ)

• Is the 330102-27-46-10-02-05 a genuine Bently Nevada product?
  Yes, we supply a brand new, original Bently Nevada 3300 XL 8 mm Proximity Probe. It is factory-sealed and meets all OEM specifications.
• What is the linear range of this 3300 XL 8 mm probe?
  The linear range is 2 mm (80 mils). It begins at approximately 0.25 mm (10 mils) from the target and extends to 2.3 mm (90 mils).
• What is the maximum length for field wiring?
  The maximum length between the 3300 XL Proximitor Sensor and the monitor is 305 meters (1,000 feet).
• What is the operating temperature for the probe tip?
  The standard probe tip operates from -52°C to +177°C (-62°F to +350°F). Do not expose the probe to temperatures below –34˚C (-30˚F) to protect the pressure seal.
• Do you have this 3300 XL probe in stock?
  Yes, we keep the 330102-27-46-10-02-05 in our global warehouse. We have stock available for immediate dispatch.
• Which approvals does this proximity probe carry?
  This specific probe (option 05) carries CSA, ATEX, and IECEx approvals for hazardous areas. It includes both intrinsic safety (ia) and non-incendive (nA/ec) certifications.
