2711P-T15C4D9 PanelView Plus 6 1500 Operator Terminal

Technical Specifications

• Manufacturer – Allen‑Bradley
• Model Number – 2711P-T15C4D9
• Product Family – PanelView Plus 6 Operator Terminals
• Series – PanelView Plus 6 1500
• Display Size – 15.0 inches diagonal
• Display Area – 304 x 228 mm (12.0 x 9.0 in.)
• Resolution – 1024 x 768 pixels, 18‑bit color
• Backlight – CCFL, 50,000 hours min at 25 °C, field replaceable
• Touch Lifespan – 1 million presses
• Memory – 512 MB Flash / 512 MB RAM
• Input Voltage – 18‑30 VDC (nominal), 18‑32 VDC range
• Communication – Ethernet, RS‑232, 2 x USB host
• Enclosure Rating – NEMA/UL Type 12, 13, 4X; IEC IP54, IP65
• Operating Temperature – 0 to 55 °C (32 to 131 °F)
• Relative Humidity – 5 to 95% non‑condensing
• Shock Rating – 30G operational
• Vibration Rating – 2G at 10 to 500 Hz
• Altitude – 2000 meters (6561 feet) maximum
• Weight – 4.2 kg (9.3 lbs) approx.
• Shipping Dimensions – 330 x 416 x 65 mm (12.97 x 16.37 x 2.55 in.)

Frequently Asked Questions

• What is the touchscreen lifespan?
  The resistive touch supports 1 million presses, and the backlight lasts 50,000 hours minimum.
• Can I use this terminal outdoors?
  It is rated NEMA 4X and IP65 for indoor use only, not for direct outdoor exposure.
• What communication protocols does the Ethernet port support?
  It supports EtherNet/IP for controller communication, application transfers, and printing.
• Does it support Microsoft file viewers?
  Yes, the extended version supports viewing Word, PowerPoint, and Excel files.
• Does the package include a memory card or software?
  It includes the terminal and accessories listed; application software is not provided.
