21000-34-00-15-039-03-02 Bently Nevada 3300 XL 8mm Assembly

Bently Nevada 21000-34-00-15-039-03-02 Proximity Probe Housing Assemblies

Key Technical Specifications

• Brand & Full Model: Bently Nevada 21000-34-00-15-039-03-02 – Proximity Probe Housing.
• Probe Option: 3300 XL 8 mm probe with a connector protector.
• Probe Cable Length: 1.0 meter (Option 00 means probe cable not required).
• Standoff Adapter: 1.5 inches for precise positioning.
• Probe Penetration: 3.9 inches allows flexible installation depths.
• Mounting Thread: 3/4-14 NPT (Option -02) – mandatory for this configuration.
• Fittings Included: One 3/4-14 NPT plug, one reducer, and a cable seal grip.
• Cable Seal Grip Grommets: Fits 1/8 to 3/16 in, 1/4 to 5/16 in, and 5/16 to 3/8 in cables.
• Housing Material: Aluminum body with a 304 stainless steel sleeve.
• Maximum (C)+(D) with Visible Probe: 17.0 inches (43.18 cm).
• Maximum (C)+(D) Dimension: 32.9 inches (83.5 cm).
• Weight: 1.1 kg (2.4 lb) typical without fittings.
• Environmental Rating: CSA Type 4 enclosure and explosion proof for hazardous areas.
• Standard Compliance: Fully meets API 670 for externally mounted housings.
• Temperature Range: Suitable for industrial environments with high thermal stability.
• Interference Rejection: The 3300 XL probe design delivers strong electrical noise immunity.

Frequently Asked Questions (FAQ)

• Q: Is the 21000-34-00-15-039-03-02 housing assembly ready for hazardous locations?
  A: Yes. It has CSA explosion proof approval and works in intrinsically safe systems.
• Q: What probe cable length does this model require?
  A: The suffix code 00 means you do not need a separate probe cable. The internal probe has a 1.0 m cable.
• Q: Does this assembly include the reverse mount proximity probe?
  A: Yes. The Bently Nevada 21000-34-00-15-039-03-02 includes a reverse mount 3300 XL 8 mm probe.
• Q: Can I use this housing with a different standoff adapter?
  A: The unit ships with a fixed 1.5 in standoff adapter (option 15). Changing it may affect the probe penetration.
• Q: How do I select the correct cable seal grip grommet?
  A: The package includes three grommets. Choose the one that matches your cable size (1/8-3/16 in, 1/4-5/16 in, or 5/16-3/8 in).
• Q: Is the 3/4-14 NPT mounting thread mandatory?
  A: Yes. You must order the -02 mounting thread option unless the standoff adapter length is -00.
• Q: What is the maximum (C)+(D) dimension for safe installation?
  A: Do not exceed 32.9 inches (83.5 cm) for the assembly with visible probe serial number.
• Q: Do you have this model in stock?
  A: Yes. We keep the 21000-34-00-15-039-03-02 in stock and ready to ship.
