177230-00-02-05 Bently Nevada Seismic Transmitter 4-20mA

Bently Nevada 177230-00-02-05 Seismic Transmitter – Reliable Vibration Monitoring

Key Technical Specifications

• Manufacturer: Bently Nevada (Made in U.S.A.)
• Product No.: 177230-00-02-05
• Measurement Range: 0 – 12.7 mm/s (0 – 0.5 in/s) peak
• Frequency Response: 3 Hz to 1 kHz (180 to 60 kcpm) ±10%
• Output Signal: 4 to 20 mA current loop (Pin A to Pin B)
• Sensitivity - Main Loop: 4 ±0.3 mA = 0.0 mm/s; 20 ±2 mA = full scale
• Full Scale Range Tolerance: ±10% of 12.7 mm/s
• Settling Time: Less than 15 seconds within 2% of final value
• Mounted Resonant Frequency: Greater than 12 kHz
• Transverse Sensitivity: Less than 5% of sensitivity
• Sensing Element: Ceramic / Shear type
• Electrical Excitation Voltage: 12 to 30 Vdc (current limited to 40 mA)

Environmental & Physical Durability

• Operating Temperature: -40°C to +85°C (-40°F to +185°F)
• Relative Humidity: To 100% non-submerged
• Case Material: 316L stainless steel
• Connector: 3-pin MIL-C-5015, also 316L stainless steel
• Mounting Hole in Body: 1/4-28 UNF
• Diameter: 25.4 mm (1.00 in)
• Height: 66.0 mm (2.60 in)
• Weight: 0.131 kg (4.62 oz)
• Shock Survivability: 9.810 m/s² (1.000 g peak) max drop test
• Sensor Seal: Hermetically sealed
• Magnetic Field Sensitivity: <20 μm/s/gauss peak; <14.7 mm/s²/gauss peak

Approvals & Electrical Isolation

• Approvals Code 05: Multiple Approvals (CSA/NRTL/C, ATEX/IECEx)
• Electrical Isolation: Greater than 10⁸ ohms
• Isolation Breakdown Voltage: 600 Vrms with less than 1 mA leakage

Connector Wiring & Signal Details

• Pin A: 4-20 mA Positive Loop (positive with reference to Pin B)
• Pin B: 4-20 mA Loop Return (negative return and common for dynamic signal)
• Pin C: Dynamic Acceleration Signal (unbuffered, referenced to Pin B)
• Output Proportionality: Output signal matches peak vibration levels.

Frequently Asked Questions (FAQ)

• Q: Is this transmitter brand new and original?
  A: Yes, we provide 100% new original Bently Nevada 177230-00-02-05 units. No used or refurbished parts.
• Q: What power supply works with this seismic transmitter?
  A: It requires 12 to 30 Vdc with current limited to 40 mA. Most PLCs and DCS internal supplies work fine (30-35 mA typical).
• Q: Can I use this transmitter in hazardous locations?
  A: Yes, approval code 05 includes CSA/NRTL/C and ATEX/IECEx certifications for safe use.
• Q: How do I interpret the 4-20 mA output?
  A: 4 mA equals 0.0 mm/s; 20 mA equals the full scale 12.7 mm/s (±10% tolerance). The signal represents peak vibration levels.
• Q: What is the frequency response range?
  A: The unit measures 3 Hz to 1 kHz (180 to 60 kcpm) with ±10% accuracy.
• Q: Does the device include a dynamic signal output?
  A: Yes, Pin C provides an unbuffered dynamic acceleration signal referenced to Pin B.
• Q: How soon will you ship my order?
  A: We ship within 5 days via FedEx, UPS, or DHL. Stock is available for immediate dispatch.
• Q: What is the return policy?
  A: We accept returns within 30 days of delivery, provided the item remains in original condition.

For any inquiries or orders, please contact us: sales@nex-auto.com or +86 153 9242 9628 (WhatsApp).
