140NOE77100C Schneider Electric - Ethernet Module

Schneider Electric 140NOE77100C Modicon Quantum Ethernet TCP/IP Module

Network and Communication Specifications

• Protocol Support: This 140NOE77100C module utilizes Ethernet Modbus TCP/IP protocol for industrial communication.
• Transmission Rate: It delivers 10/100 Mbit/s data transfer speeds for efficient network performance.
• Web Server: A Class B20 web server enables diagnostics via predefined web pages and data editor functions.
• Communication Services: It supports I/O scanning, Modbus TCP messaging, and rack viewer capabilities.
• Redundancy: This Ethernet module features hot standby redundant architecture for enhanced system reliability.
• Physical Interfaces: It offers MT/RJ for 100BASE-FX fiber optic and RJ45 for 10BASE-T/100BASE-TX twisted pair connections.

Diagnostic and Status Indicators

• Module Status LEDs: Nine LEDs monitor data rate, collision detection, download mode, and module fault conditions.
• Network Status: Dedicated LEDs display RUN status, full-duplex mode, module ready, and link activity.
• Activity Monitoring: The TxAct/RxAct LED indicates transmission and reception activity for quick troubleshooting.
• Rack Status: An Active LED confirms the rack operational state for system verification.
• Speed Indication: Separate LEDs identify 10 Mbps or 100 Mbps data rate operation.

Environmental and Operating Conditions

• Operating Temperature: The 140NOE77100C functions reliably from 0 to 60 degrees Celsius ambient temperature.
• Storage Range: It withstands storage temperatures from -40 to 85 degrees Celsius for extreme condition tolerance.
• Humidity Resistance: This module handles up to 95 percent relative humidity without condensation.
• Operating Altitude: It performs at altitudes up to 4500 meters above sea level for high-elevation installations.
• Protective Treatment: Conformal coating with Humiseal 1A33 enhances durability against environmental factors.
• EMC Resistance: It withstands 4 kV contact discharge and 8 kV air discharge per IEC 801-2 standards.
• Electromagnetic Fields: Resistance reaches 9.1 V/m from 80 to 1000 MHz per IEC 801-3 requirements.

Electrical and Physical Specifications

• Power Supply: The 140NOE77100C draws 750 mA at 5 V DC via the rack power supply.
• Module Format: It uses standard Modicon Quantum format for consistent panel installation.
• Protection Rating: IP20 degree of protection safeguards against solid objects larger than 12mm.
• Net Weight: This Ethernet module weighs 0.345 kg or 0.761 lb for lightweight handling.
• Dimensions: Standard Quantum form factor ensures compatibility with existing rack systems.

Frequently Asked Questions (FAQ)

• Is the 140NOE77100C a brand new module? Yes, we supply it as a brand new and original Schneider Electric product.
• Do you have this Ethernet module in stock? Yes, we maintain the 140NOE77100C in stock for immediate shipment.
• How quickly can you ship this TCP/IP module? We ship all orders within 5 days via DHL, FedEx, or UPS.
• What is your return policy for this item? We accept returns within 30 days of delivery for this module.
• What is the maximum operating temperature? This module operates reliably from 0 to 60 degrees Celsius.
• Does this module support redundancy? Yes, it features hot standby redundant architecture for enhanced reliability.
• What protocols does the 140NOE77100C support? It supports Ethernet Modbus TCP/IP with I/O scanning and messaging.
• What physical interfaces are available? It offers MT/RJ fiber optic and RJ45 twisted pair connections.
• Does this module include conformal coating? Yes, it features Humiseal 1A33 conformal coating for environmental protection.
• What is the maximum operating altitude? This module performs at altitudes up to 4500 meters above sea level.
