140DAI54300C Schneider 115VAC 16-Channel Input Module

Schneider Electric 140DAI54300C Modicon Quantum Discrete Input Module

• The 140DAI54300C from Schneider Electric provides 16 discrete input channels for your Modicon Quantum automation system. It operates reliably at a standard voltage of 115 VAC, making it suitable for diverse industrial applications.
• This 140DAI54300C module requires only one input word for addressing, which simplifies integration into existing control architectures. Engineers appreciate its straightforward setup and the robust performance of the Modicon Quantum series.
• Each channel features an input current range of 11.1 to 13.2 mA, with a maximum leakage current of just 2.1 mA to ensure signal integrity. The module draws 180 mA from the bus and dissipates a maximum power of 5.5 W.
• Schneider Electric built this input module to comply with UL 508 and CSA standards, carrying the CE mark for international markets. The conformal coating protects internal circuits from moisture and dust, enhancing longevity in harsh environments.
• The 140DAI54300C operates flawlessly within an ambient temperature range of 0 to 60 °C. Its compact standard format weighs only 0.3 kg, allowing easy installation in crowded cabinets.

Technical Specifications

• Brand: Schneider Electric | Model: 140DAI54300C | Type: Discrete Input Module
• Input Channels: 16 channels at 115 VAC, with high noise immunity for reliable operation in electrically noisy environments.
• Input Characteristics: Current 11.1 to 13.2 mA per channel; leakage current ≤ 2.1 mA ensures accurate off-state detection.
• Power & Bus: Requires 180 mA from Quantum bus; max power dissipation 5.5 W, keeping energy consumption low.
• Environmental Resistance: Conformal coating protects against dust/humidity; operating temperature 0 to 60 °C for continuous duty.
• Certifications & Standards: UL 508, CSA, CE marked – meets global industrial safety requirements.

Frequently Asked Questions

• How quickly do you ship and which carriers do you use? We ship within 5 days after order confirmation via DHL, FedEx, or UPS – whichever suits your location best.
• What is the return policy for this module? We offer a 30‑day return window for unused items in original condition. Contact us to arrange.
• Can this 115 VAC module work with 230 VAC signals? No, the 140DAI54300C is designed specifically for 115 VAC nominal. Using higher voltage may damage inputs.
• Does the conformal coating make it explosion-proof? No, the coating protects against environmental contaminants but does not make the module explosion-proof. Follow standard area classifications.
• For any pre-sales or technical questions, we provide prompt email support.
• For any pre-sales or technical questions, we provide prompt email support.
