140CPU21304C Schneider Processor Unit 768KB

Schneider Electric 140CPU21304C Modicon Quantum Conformal Coated CPU Module

Memory and Processing Capabilities

• Provides 768 KB of RAM for robust data handling and complex automation tasks
• Includes 16 KB of dedicated program memory for efficient code execution and storage
• Executes Boolean operations in approximately 0.3 µs, ensuring rapid response for time-critical processes
• Supports advanced math instructions for sophisticated computational requirements in industrial applications

Communication and Connectivity Features

• Integrates 1 x RS232 Modbus port for direct serial communication with field devices
• Offers 1 x Modbus Plus port for high-speed industrial network connectivity
• Supports both local and remote I/O configurations, providing flexibility for distributed system architectures
• Enables seamless integration into existing Modicon Quantum networks without complex reconfiguration

Reliability and Environmental Protection

• Features conformal coating that shields circuitry from humidity, dust, and corrosive agents
• Includes battery-backed RAM to preserve critical data during unexpected power interruptions
• Operates reliably in temperatures from 0 to 60°C, suitable for varied industrial settings
• Contains integrated watchdog function for automatic system monitoring and fault recovery

Frequently Asked Questions

• What makes the 140CPU21304C suitable for harsh environments?
  › The module features conformal coating that protects electronic components from moisture, dust, and chemical exposure.
• How much memory does this CPU provide for programs?
  › It offers 768 KB of RAM for data and 16 KB of program memory for application code storage.
• What communication protocols does the 140CPU21304C support?
  › It includes one RS232 Modbus port and one Modbus Plus port for flexible industrial networking.
• Can this CPU retain data during a power failure?
  › Yes, battery-backed RAM preserves critical data and program states when power disconnects.
• What do the status LEDs indicate on this module?
  › LEDs show RUN (operation), ERR (errors), I/O (input/output status), and COMM (communication activity).
• Does this processor support remote I/O configurations?
  › Absolutely, it handles both local and remote I/O, making it versatile for distributed control systems.
