TSXDEZ12D2K Schneider 12 Input Module TSX Micro Series

Schneider Electric TSXDEZ12D2K Digital Input Module for Modicon TSX Micro

Technical Specifications

• Brand: Schneider Electric
• Model: TSXDEZ12D2K
• Category: Digital input module
• Series: Modicon TSX Micro
• Input points: 12 digital inputs
• Rated voltage: 24 VDC
• Operating voltage range: 19 to 30 VDC
• Module type: Discrete input, TSX Micro platform
• Form factor: Plug-in module with terminal block
• Net weight: Approx. 0.23 kg

Installation Guide

• Slide the module into a free slot on the Modicon TSX Micro rack.
• Check that rack supply voltage matches the module rating before insertion.
• Wire the field devices to the terminal block using suitable conductor sizes.
• Keep all input supply voltages inside the 19 to 30 VDC window.
• Label each channel clearly to simplify future maintenance and troubleshooting.
• Run a quick channel test through the PLC software after wiring.

Environmental and Immunity Notes

• The module follows the standard ambient limits of the Modicon TSX Micro series.
• Channel design tolerates typical electrical noise found on factory floors.
• Wide 19 to 30 VDC input range absorbs small supply fluctuations.
• Proper grounding of the rack improves noise rejection in dense cabinets.

Package Contents

• One TSXDEZ12D2K digital input module
• One terminal block attached to the module
• Reference documentation sheet

Shipping Methods

• FedEx International Priority for express delivery
• UPS Worldwide Saver for reliable transit
• DHL Express for door-to-door service

Frequently Asked Questions

• How many inputs does the TSXDEZ12D2K provide? The module offers twelve digital input points on one unit.
• What voltage does this module need? It uses a 24 VDC rated supply and works from 19 to 30 VDC.
• Which platform supports this module? The TSXDEZ12D2K fits the Modicon TSX Micro automation series.
• Can I test channels before full commissioning? Yes, the PLC software lets you force and monitor each input.
• Is the module in stock? Yes, we hold stock and dispatch within 5 days.
• What is the return policy? We accept returns within 30 days of delivery.
