140NOC78100 Schneider Electric Modbus TCP EtherNet/IP Module

140NOC78100 Schneider Electric Modicon Quantum Ethernet Control Network Module

Technical Specifications

• Brand: Schneider Electric
• Model: 140NOC78100
• Category: Ethernet Control Network Module
• Series: Modicon Quantum automation platform
• Product Compatibility: 140CPU6xxxx processors
• Protocols: Modbus TCP and EtherNet/IP
• Transmission Rate: 10/100 Mbit/s, full duplex
• Maximum Connections: 64 simultaneous connections
• Redundancy: Hot standby redundant architecture
• Topology: Daisy chain loop and redundant ring
• Ethernet Ports: RJ45 10BASE-T/100BASE-TX with embedded 4-port switch
• Communication Services: NTP time sync, FDR server, CIP implicit and explicit messaging
• Network Features: Embedded router, SNMP agent, QoS, SMTP e-mail notification
• Additional Services: DHCP/BootP server, RSTP, Device Type Manager (DTM)
• Transmission Medium: Twisted pair
• Supply: Via the rack power supply
• Local Signalling: Six LEDs for Active, Ready, Mod Status, and Net Status
• Module Format: Standard
• Weight: 0.345 kg (0.761 lb)
• Protection Rating: IP20
• Operating Temperature: 0 to 60 °C (32 to 140 °F)
• Relative Humidity: 10 to 95 % at 60 °C without condensation
• Standards: UL 508, EN 55011, EN 61131-1/2, FM Class 1 Division 2, CSA C22.2 No 142
• Certifications: Hazardous location Class 1 Division 2, C-tick, GOST, LR, Merchant Navy, CE
• Manufacturer: Schneider Electric

Installation Guide

• Insert the module into a free slot on the Modicon Quantum rack.
• Confirm the rack supplies power before you power up the system.
• Connect network cables to the RJ45 ports and build your daisy chain or ring.
• Assign the IP address through the embedded DHCP/BootP server or your tool.
• Check the six status LEDs to confirm healthy bus and network states.
• Test Modbus TCP and EtherNet/IP traffic before you start production.

Package Contents

• One 140NOC78100 Ethernet control network module
• One installation reference guide
• Protective packaging for safe transit

Shipping Options

• FedEx express delivery for fast global shipment
• UPS reliable door-to-door service
• DHL international logistics coverage

Frequently Asked Questions

• Q: Which protocols does the 140NOC78100 support?
  A: It supports Modbus TCP and EtherNet/IP at 10/100 Mbit/s.
• Q: How many connections can the module handle?
  A: It handles up to 64 simultaneous connections.
• Q: Does it support redundant architectures?
  A: Yes, it supports hot standby redundant architecture with ring topologies.
• Q: Which processors does it work with?
  A: It works with 140CPU6xxxx processors on the Modicon Quantum platform.
• Q: Does the module include a web server?
  A: Yes, it has an embedded web server and SNMP agent.
• Q: What is the operating temperature range?
  A: It operates from 0 to 60 °C (32 to 140 °F).
• Q: How many Ethernet ports does it provide?
  A: It provides four RJ45 ports through an embedded switch.
• Q: How do you handle shipping and delivery?
  A: We ship within 5 days using DHL, FedEx, and UPS.
• Q: What is your return policy?
  A: We support 30-day returns on all orders.
• Q: Is the product new and original?
  A: Yes, we supply brand-new original units, and we hold stock for fast fulfillment.
