TSX3705001 Schneider Electric Micro PLC CPU Module

Schneider Electric TSX3705001 PLC CPU Module – Product Overview

Technical Specifications

• Brand: Schneider Electric
• Model: TSX3705001
• Category: Programmable Logic Controller CPU Module
• Series: Modicon TSX Micro (TSX 3705 AC)
• Power Supply: 24 V DC
• Digital Inputs: 16 channels, 24 V DC
• Digital Outputs: 12 relay outputs
• Expansion Slots: 2 slots for additional modules
• I/O Capacity: Up to 144 points via expansion modules
• Program Memory: 64 KB, expandable
• Communication Ports: RS232/RS485 with Modbus RTU support
• Execution Time: 0.25 µs per Boolean instruction
• Operating Temperature: 0 to 60 °C
• Storage Temperature: -25 to 70 °C
• Relative Humidity: 10–95% without condensation
• Protection: Overload and short-circuit protection
• Weight: 1.49 kg

Installation Guide

• Mount the CPU module on a DIN rail or panel inside a control cabinet.
• Connect the 24 V DC power supply according to the wiring diagram.
• Insert I/O or communication modules into the two available slots.
• Connect programming cables to the RS232 or RS485 port.
• Tighten all terminal screws to the specified torque.
• Verify connections before applying power to the system.
• Use PL7 Micro software for programming and configuration.

Package List

• 1 x Schneider Electric TSX3705001 PLC CPU Module
• 1 x Terminal block set
• 1 x Mounting clip for DIN rail

Shipping Methods

• FedEx
• UPS
• DHL

Frequently Asked Questions

• Q: Is this product new and original?
  A: Yes, we supply brand new original Schneider Electric TSX3705001 units.
• Q: Do you have stock available?
  A: Yes, we keep this model in stock for immediate order processing.
• Q: How fast do you ship?
  A: We dispatch orders within 5 days after payment confirmation.
• Q: What shipping carriers do you use?
  A: We ship via FedEx, UPS, and DHL for reliable global delivery.
• Q: Can I return the product?
  A: Yes, we accept returns within 30 days of delivery.
• Q: What is the power supply requirement?
  A: This module requires a 24 V DC power supply.
• Q: How many built-in I/O points does it have?
  A: It provides 16 digital inputs and 12 relay outputs.
• Q: Does it support Modbus communication?
  A: Yes, the RS232/RS485 ports support Modbus RTU.
• Q: What programming software does it use?
  A: It uses PL7 Micro software for configuration.
• Q: Can I expand the I/O capacity?
  A: Yes, it supports up to 144 I/O points via expansion modules.
