IC754VGL06CTD Loaded Terminal GE Fanuc

Product Overview: GE Fanuc QuickPanel View IC754VGL06CTD HMI Terminal

Core Display & Processing Specifications

• The IC754VGL06CTD features a vibrant 6-inch colored TFT display with 65,536 colors.
• It delivers a crisp 320 x 240 pixel resolution for clear visualization of runtime applications.
• Powering the unit is a high-performance Intel XScale PXA255 processor at 300 MHz (400 MHz capable).
• The operator interacts via a precise 12-bit analog resistive touchscreen interface.
• The front bezel is constructed from durable Valox 357U material for industrial longevity.

Memory & Operating System

• This model comes loaded with 64 MB of Flash memory, 64 MB DRAM, and 512 KB SRAM.
• The SRAM includes battery-backed retention for preserving data through power cycles.
• It runs on a licensed Microsoft Windows CE (Compact Embedded) Operating System.
• The OS provides a user-friendly, Windows-like environment with Pocket Internet Explorer.
• A 100-pin DIMM slot allows memory expansion using compatible SDRAM modules.

Communication & Interface Ports

• It is equipped with two (2) 10/100 Mbps Ethernet interfaces for networked connectivity.
• Serial communication includes one combo port (RS232/RS422/RS485) and one dedicated RS232 port.
• The unit also provides two (2) USB interfaces for peripheral connection and data transfer.
• It includes an HMI-CAB-C94 communication cable to facilitate initial setup and connections.
• These ports support communication with one or multiple machines in complex control systems.

Frequently Asked Questions (FAQ)

• Q: What is the main difference in the "Loaded" version?
  A: The IC754VGL06CTD comes pre-loaded with Proficy Machine Edition software and Windows CE OS, ready for development.
• Q: How many Ethernet ports does this HMI have?
  A: It features two (2) independent 10/100 Mbps Ethernet interfaces for flexible network integration.
• Q: Can the memory be expanded on this unit?
  A: Yes, via a 100-pin DIMM slot using compatible modules like IC754ACC32MEM or IC754ACC64MEM.
• Q: What is your shipping and return policy for obsolete parts?
  A: We ship via FedEx, UPS, and DHL and offer a 30-day return policy on all supplied units.

For sourcing the discontinued IC754VGL06CTD or other QuickPanel View models, contact our specialized obsolete parts team.
