Honeywell - FC-RO-1024 Output Module

FC-RO-1024 Relay Output Module: 10-Channel Isolated Control

Module Overview & Key Features

• Channel Configuration: The module offers ten potential-free relay contact output channels for complete load isolation.
• Load Handling: Designed for switching resistive or inductive loads with appropriate external protection.
• System Safety: All relay coils are controlled by the integrated watchdog function for failsafe de-energization.
• Product Variants: Available as FS-RO-1024 and FC-RO-1024 compliant versions.

Detailed Technical Specifications

• Contact Rating: Each relay channel can switch up to 2 A continuous current.
• Voltage Ratings: Maximum contact voltage is 30 V AC / 36 V DC per IEC 61010-1 standards.
• Power Capacity: Supports maximum switched power of 100 W / 1000 VA.
• Contact Material: Features durable gold flash over silver alloy contacts for reliable switching.
• Load Capacitance: Maximum load capacitance per channel is 100 nF.
• Inductive Load Support: Requires an external suppression diode for inductive load protection.

Relay Life & Electrical Characteristics

• Electrical Life: Provides 1,000,000 switch operations with resistive loads.
• Inductive Load Life: Offers 100,000 switch operations with AC inductive loads (Pf 0.4).
• Module Power: Requires 5V DC at 25 mA and 24V DC at 120 mA for operation.
• WDG Input: Watchdog monitoring draws 4 mA from the control system.

Physical Design & Compliance

• Mounting Size: Compact design requires only 4 TE, 3 HE (4 HP, 3U) of panel space.
• International Approvals: The FC-RO-1024 module carries CE, TÜV, UL, and CSA approvals.
• Safety Standard: Compliant with IEC 61010-1 standards for electrical safety.

Packaging & Delivery Information

• Packaging: Includes the FC-RO-1024 relay module and necessary mounting hardware.
• Stock Status: This relay output module is brand new and original, available from stock.
• Shipping: We ship worldwide using DHL, FedEx, and UPS within 5 business days.

Frequently Asked Questions (FAQ)

• Is the FC-RO-1024 module new and authentic?
  Yes, we supply only 100% new and original FC-RO-1024 modules in factory packaging.
• What is the maximum load per relay channel?
  Each relay can switch 2 A at 36 V DC or 30 V AC, handling up to 70-100W loads.
• Do the relay contacts provide isolation?
  Yes, all ten channels feature completely potential-free (isolated) relay contacts.
• How long do the relays last?
  Contact life is 1 million operations with resistive loads and 100,000 operations with inductive loads.
• What is your shipping and return policy?
  We ship within 5 days via major carriers and offer a 30-day return policy.
