GE Fanuc - IC697CHS771 6-Slot PLC Rack

GE Fanuc IC697CHS771 Series 90-70 PLC Rack

Key Technical Specifications

• Brand/Manufacturer: GE Fanuc
• Model: IC697CHS771
• Series: Series 90-70
• Product Type: PLC Rack
• Total Slots: 6 slots per system (plus dedicated power supply slot)
• Systems Supported: 2 Systems
• I/O Bus Current Required: 0.5 Amps
• Voltage Compatibility: AC and DC Inputs
• Current Draw (120/240V AC or 125V DC): 20A (100W) or 11A (55W)
• Current Draw (24/48V DC): 18A (90W)
• Max System Cable Length: 50 Feet (15.2 meters)

Product Features & Design

• The rack supports two separate PLC systems within a single chassis, optimizing control panel space.
• It offers six slots per system for hosting a variety of CPU, communication, and I/O modules.
• A dedicated slot on the far left is designed specifically for the system power supply unit.
• The IC697CHS771 provides flexible power options, supporting both AC and DC voltage inputs.
• Proper installation requires all racks in the system to share the same electrical ground potential for safety and noise reduction.

Frequently Asked Questions (FAQ)

• Q: How many total slots does the IC697CHS771 rack have?
  A: It has a total of 12 module slots (6 per system), plus one additional dedicated slot for the power supply.
• Q: Can I use this rack with just one system?
  A: Yes, the IC697CHS771 can reliably host one system, leaving room for future expansion to a second system.
• Q: What is the maximum cable length for the bus?
  A: The cable from the BTM to the last BRM must not exceed 50 feet (about 15.2 meters) for reliable communication.
• Q: What power supplies are compatible with this rack?
  A: The rack supports various inputs: 120/240V AC, 125V DC (at 11A or 20A), and 24/48V DC (at 18A).
• Q: Is a dedicated power supply slot included?
  A: Yes, there is a specialized slot on the far left specifically designed to house the power supply module.
