Bently Nevada 330905-00-09-05-02-05 Probe | 3300 NSv M10x1

Bently Nevada 330905-00-09-05-02-05: M10x1 3300 NSv Vibration Probe for Metric Installations

Complete Suffix Configuration: 330905-00-09-05-02-05

• Brand: Bently Nevada
• Series: 3300 NSv Proximity Transducer System
• Base Model: 330905 - 5mm NSv probe
• -00: M10x1 thread, 00mm unthreaded tip (full thread engagement)
• -09: 90mm metric case length
• -05: 0.5 meter integral cable with FEP jacket
• -02: Miniature coaxial ClickLoc connector, standard cable type
• -05: Multiple agency approvals (CSA, ATEX, IECEx)

Precision Technical Specifications

• Linear Range: 1.5 mm. This provides full-scale measurement for radial vibration and thrust position.
• Recommended Gap: 1.0 mm from target. This centers operation within the linear window.
• Accuracy: ±0.06 mm deviation from straight line. No field trimming required.
• Incremental Scale Factor: 7.87 V/mm nominal. Factory calibrated to 200 mV/mil standard.
• Scale Factor Tolerance: +12.5%/-20%. Each unit ships with certified actual value.
• Frequency Response: 0 to 10 kHz. System captures static position and dynamic events.
• Output Signal: -1 to -13 Vdc proportional to gap distance. Compatible with all 3300 RAM monitors.
• Temperature Range: -52°C to +177°C probe tip. Electronics rated -35°C to +65°C.
• Pressure Resistance: Viton O-ring seal. Factory installed but not pressure tested.
• Environmental Protection: FEP cable jacket resists steam, caustics, and hydrocarbon exposure.
• EMI/RFI Shielding: Braided shield rejects variable frequency drive interference.

Mechanical Specifications and Mounting

• Thread Specification: M10x1 metric coarse thread. Compatible with international mounting standards.
• Case Length: 90mm from mounting face to cable exit. Ideal for thin-bearing housings.
• Tip Configuration: 00mm unthreaded section. Full thread engagement provides maximum clamping force.
• Mounting Torque: Hand tight only. Use 0.56 N·m maximum for M10x1 threads.
• Target Specification: Minimum 13mm diameter flat. AISI 4140 steel or magnetic equivalent.
• Minimum Bend Radius: 25.4 mm. Protect the 0.5 meter cable from sharp edges.
• Connector: Miniature coaxial ClickLoc. Provides positive retention in high-vibration environments.

Box Contents

• 1x Factory-sealed Bently Nevada 330905-00-09-05-02-05 proximity probe
• 1x Calibration certificate with individual ISF values
• 1x Viton O-ring installed, one spare included

Shipping and Availability

• Inventory: Genuine Bently Nevada stock. All units are factory-new and sealed.
• Dispatch: Orders process and ship within 5 business days.
• Carriers: FedEx International Priority, UPS Worldwide Express, DHL Express Easy.
• Returns: 30-day acceptance window. Product must remain in original unopened packaging.

Frequently Asked Questions

• What is the difference between -00 and -05 thread configurations? The 330905-00-09-05-02-05 uses M10x1 metric threads with no unthreaded tip. The -05 suffix indicates 50mm unthreaded section for inch-series installations.
• Can I use this M10 probe in a 3/8-24 UNF hole? No, M10x1 and 3/8-24 UNF threads differ in pitch and diameter. Use only in metric tapped holes.
• Does the -05 approval suffix cover Zone 0 areas? Yes, multiple approvals include ATEX II 1G and CSA Intrinsically Safe for Zone 0.
• Why does this probe have 00mm unthreaded length? Some installations require threads along the entire case for maximum grip in shallow housings.
• What is the incremental scale factor tolerance? Bently Nevada certifies each 330905-00-09-05-02-05 with actual ISF. Tolerance band is +12.5%/-20% from 7.87 V/mm.
• Is the Viton O-ring suitable for hydrogen service? Yes, Viton exhibits low permeability and excellent resistance to hydrogen embrittlement.

Technical Documentation

• Download complete system specifications and installation drawings: 3300 XL NSv Proximity Transducer System Datasheet - 147385
• This document includes metric conversion tables, target material effects, and driver compatibility charts.
