Bently Nevada 330104-00-10-05-02-CN 8mm Proximity Probe

Core Product Overview

This system combines a probe, cable, and proximitor sensor into one reliable unit.

• Brand & Model: This is an original component from Bently Nevada, part of the 3300 XL series.
• Product Type: The item is an 8 mm Proximity Probe with integrated cable and connector.
• Key Identifier: The full part number is 330104-00-10-05-02-CN.
• Construction: The probe tip uses tough Polyphenylene sulfide (PPS) material. The outer case is strong AISI 303 or 304 stainless steel.
• Sealing: A reliable Viton® O-ring seals the probe against pressure and contaminants.

Detailed Technical Specifications

Here are the key performance parameters for this monitoring component.

• Electrical Interface: It uses a Miniature coaxial ClickLoc connector for a secure link.
• Cable Length: The total cable length for this option is 0.5 meter (1.6 feet).
• Probe Dimensions: The case length is 100 mm (Option 10). It has an M10 x 1 mounting thread.
• DC Resistance: The probe's nominal resistance (R_PROBE) is 7.45 Ω ± 0.50 Ω for the 0.5m cable.
• Power Supply: The matching 3300 XL Proximitor needs -17.5 Vdc to -26 Vdc at 12 mA max.
• Output: The proximitor provides a stable output with a 50 Ω output resistance.
• Sensitivity: Supply voltage variation has minimal effect (< 2 mV/V change).

Environmental & Safety Ratings

This product meets strict standards for use in challenging and hazardous locations.

• Temperature Range: The probe operates from -55°C to +232°C based on its T1 classification.
• Safety Approvals: This CN option includes specific country safety certifications.
• Hazardous Area Use: It supports Class I, Zone 0 installations with intrinsic safety (ia) barriers. It is also suitable for Zone 2 areas with non-incendive (nA, ec) protection.
• Calibration Target: For best accuracy, the system uses an AISI 4140 steel target. The ideal probe gap is 1.27 mm (50 mils).

Frequently Asked Questions

• Q: Is this product new and genuine?
  A: Yes, every item we sell is brand new and 100% original from Bently Nevada.
• Q: Do you have this probe in stock?
  A: We maintain strong stock levels for the 330104-00-10-05-02-CN. Most items are ready to ship.
• Q: How soon will my order ship?
  A: We process and ship orders within 5 business days after payment confirmation.
• Q: What logistics options do you offer?
  A: We use reliable express services including DHL, FedEx, and UPS for fast delivery.
• Q: What is your return policy?
  A: We offer a 30-day return window for unused items in original condition.
• Q: What is the probe's electrical resistance?
  A: The specified probe resistance for this 0.5m model is 7.45 Ohms ± 0.50 Ohms.
• Q: What material is the probe tip made of?
  A: The tip is made from durable Polyphenylene sulfide (PPS) to withstand harsh environments.
