Bently Nevada 200355-13-00-00 Accelerometer | Magnetic Base

Bently Nevada 200355-13-00-00 Accelerometer with Magnetic Base

Complete Technical Specifications for 200355-13-00-00

• Full Model Configuration: The Bently Nevada 200355-13-00-00 includes a #28 female thread for mounting. The "13" designator specifies the integral magnetic base with 50 lbf (222 N) holding force. The "00" approvals code indicates no intrinsic safety certifications.
• Sensitivity and Range: This accelerometer delivers 100 mV/g ±20% sensitivity (10.2 mV/m/s² ±20%). It measures vibration accurately across a ±50 g dynamic range. This sensitivity range suits most industrial rotating machinery applications.
• Frequency Response: The 200355-13-00-00 operates from 30 to 600,000 CPM (0.5 to 10,000 Hz). This wide frequency response captures both slow-speed and high-frequency vibrations. Users can detect early bearing faults and imbalance conditions effectively.
• Mechanical Dimensions: The magnetic base measures 25 mm (0.98 inches) in diameter. Total height with base attached reaches 2.10 inches (5.33 cm). The complete assembly weighs only 0.075 kg for easy handling.
• Electrical Parameters: You must supply 18–28 VDC excitation at 2–20 mA. Output bias voltage maintains between 8 and 12 VDC. Output impedance stays below 150 Ohms for signal purity.
• Durability Features: The connector withstands over 1,000 mating cycles without performance loss. Annual sensitivity drift remains below 0.5%. The sensor survives 5,000 g peak shock events.
• Environmental Tolerance: Operating temperature spans -54°C to +121°C. The design handles 100% condensing humidity. Discharge time constant meets or exceeds 0.3 seconds for quick settling.

Magnetic Base Installation Guidelines

• Mounting Surface Requirements: The 200355-13-00-00 magnetic base requires clean, flat ferrous surfaces. Surface roughness affects holding force and frequency response. Grind or file measurement points flat before attaching the sensor.
• Magnet Engagement: Engage the 50 lbf (222 N) magnetic base by rotating the on/off lever. Ensure full contact between magnet and machine surface. Test secure attachment before taking measurements.
• Positioning Tips: Mark measurement locations for repeatability during route-based data collection. The 200355-13-00-00 allows rapid relocation between predefined points. This flexibility speeds up comprehensive machinery surveys.
• High-Frequency Considerations: Apply a thin coupling fluid to the mounting surface. This practice improves high-frequency response up to 10 kHz. The magnetic base provides adequate stiffness for most applications.

Frequently Asked Questions About 200355-13-00-00

• What makes the 200355-13-00-00 different from other 200355 models?
  The 200355-13-00-00 features an integral magnetic base with 50 lbf holding force. Other configurations use stud mounting or different attachment methods. This model suits temporary measurements and route-based data collection.
• How strong is the magnetic base on this accelerometer?
  The magnetic base provides 50 lbf (222 N) holding force on clean steel surfaces. This force keeps the 200355-13-00-00 secure during vertical or overhead measurements. Always verify secure attachment before releasing the sensor.
• Can I remove the magnetic base for stud mounting?
  Yes, the 200355-13-00-00 includes a #28 female thread for alternative mounting. You can attach studs or adapters to this thread. This flexibility increases application versatility.
• What maintenance does the magnetic base require?
  Keep the magnet surface clean and free of metal debris. Inspect the on/off lever mechanism periodically for smooth operation. The 200355-13-00-00 requires no lubrication or special care.
• Does the magnetic base affect high-frequency measurements?
  The 200355-13-00-00 magnetic base maintains response up to 10 kHz with proper surface preparation. Use coupling fluid for best high-frequency performance. Stud mounting provides slightly higher frequency response for critical applications.
• What is the typical lead time for this configuration?
  We stock the 200355-13-00-00 for immediate shipment. Most orders process within 24 hours. International delivery via FedEx, UPS, or DHL takes 3-5 business days.

Download the complete Bently Nevada 200355-13-00-00 technical datasheet here: 200350 and 200355 Accelerometers PDF
