330904-00-15-05-02-00 New NSv Proximity Probes Bently Nevada

Bently Nevada 3300 NSv Proximity Probe - High-Performance Monitoring

Detailed Model Suffix Information

• 330904 – 3300 NSv Armored Proximity Probe, M8x1 Thread
• 00 – 0 mm Unthreaded Length
• 15 – 150 mm Case Length
• 05 – 0.5 Meter Integrated Cable
• 02 – Standard, Unprotected Cable Exit
• 00 – No Agency Approvals Required

Complete Technical Specifications

• Brand & Model: Bently Nevada 330904-00-15-05-02-00
• Measurement Range: 0.25 to 1.75 mm (10 to 70 mils)
• Output Sensitivity: 7.87 V/mm (200 mV/mil)
• Linearity (Accuracy): ±0.06 mm (±2.3 mils) maximum deviation
• Frequency Response: DC to 10 kHz
• Operating Temperature: –52 °C to +177 °C (–62 °F to +351 °F)
• Probe Tip Material: Chemical-Resistant Polyphenylene Sulfide (PPS)
• Probe Case Material: Durable AISI 304 Stainless Steel
• Cable Type: 75 Ohm, FEP Insulated Triad Cable
• Connector: Miniature ClickLoc for Tool-Free Service

Installation & Setup Guide

• Hand-tighten the probe body to the specified torque of 5.1 N·m (45 lb-in).
• Maintain an initial air gap of approximately 1.0 mm between the probe tip and the target.
• Use a three-conductor shielded cable with 16 to 24 AWG wire size.
• Avoid sharp bends by keeping the cable radius above 25 mm at all times.
• Route the probe wiring away from sources of strong electrical interference.

Frequently Asked Questions (FAQ)

• Q: What is the main application for this Bently Nevada probe?
  A: This 330904-00-15-05-02-00 model is designed for precise shaft position and vibration measurement.
• Q: Is this product in stock for immediate shipment?
  A: Yes, we typically have this specific Bently Nevada probe model available in our inventory.
• Q: How does the temperature range affect installation?
  A: Its wide range from -52°C to +177°C allows use in extremely cold or hot machinery environments.
• Q: What is the advantage of the ClickLoc connector?
  A: The ClickLoc allows for quick, tool-free connection and disconnection, simplifying maintenance.
• Q: What is your return policy if the product does not fit?
  A: We offer a 30-day return window for unused products in their original packaging.

For complete engineering data, electrical schematics, and application notes, download the official datasheet here: 3300 XL NSv Proximity Transducer System Datasheet - 147385.

For technical support, volume pricing, or specific application questions, please reach out to our team.
