330707-00-62-10-02-05 Bently Nevada 3300 XL 1m Probe

Key Technical Specifications

• Manufacturer: Bently Nevada (Made in U.S.A).
• Model Number: 330707-00-62-10-02-05.
• Probe Type: 3300 XL 11 mm Proximity Probe without armor.
• Thread Specification: 5/8-18 UNF probe case thread.
• Unthreaded Length: 0.0 inches (Option 00).
• Overall Case Length: 6.2 inches (Option 62).
• Total Probe Length: 1.0 metre (3.3 feet, Option 10).
• Cable and Connector: Miniature coaxial ClickLoc connector with standard cable (Option 02).
• Agency Approval: Multiple approvals (Option 05).

Material and Environmental Ratings

• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial FEP insulated cable.
• Operating Temperature: -51°C to +177°C (-60°F to +351°F).
• Pressure Seal: Viton O-ring design for differential pressure sealing.

Electrical and Mechanical Data

• Probe DC Resistance (RPROBE): 5.9 ± 0.5 ohms (Center to Outer Conductor).
• Maximum Thread Engagement: 0.938 inches.
• Maximum Rated Torque: 45.2 N•m (400 in•lb).
• Recommended Mounting Torque: 15.2 N•m (133 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 inch) with or without armor.
• Recommended Connector Torque: Finger tight, maximum 0.565 N•m (5 in•lb).

Frequently Asked Questions (FAQ)

• Is this probe new and original?
  Yes, we supply 330707-00-62-10-02-05 as brand new, original Bently Nevada stock.
• What is the operating temperature range?
  The probe operates from -51°C to +177°C (-60°F to +351°F).
• Does this probe work with any extension cable?
  No, this 1.0-metre probe requires the matching one-metre Proximitor Sensor for correct calibration.
• What thread size does the probe case use?
  It uses a 5/8-18 UNF thread with a maximum engagement of 0.938 inches.
• How should I torque the probe during installation?
  Apply the recommended torque of 15.2 N•m (133 in•lb) and never exceed 45.2 N•m (400 in•lb).
• Do you have this item in stock?
  Yes, we maintain inventory and can ship within 5 days.
