330707-00-15-10-02-05 Bently Nevada 3300 XL 11 mm Probe

Bently Nevada 3300 XL 11 mm Proximity Probe - Model 330707-00-15-10-02-05

Technical Specifications

• Brand & Model: Bently Nevada 330707-00-15-10-02-05 - 3300 XL 11 mm probe
• Measurement Range: 11 mm proximity sensing for shaft position and vibration
• Frequency Response: 0 to 10 kHz for dynamic displacement measurements
• Sensitivity: 7.87 mV/μm (200 mV/mil) typical for linear range
• Linearity: Within ±0.025 mm for the entire 2 mm linear range
• Resolution: Sub-micrometer resolution for precise vibration analysis
• Operating & Storage Temperature: -52°C to +177°C (-62°F to +351°F)
• Low Temperature Caution: Exposure below -34°C (-30°F) may damage the pressure seal
• Environmental Tolerance: Withstands high humidity, oil, and dust contamination
• Immunity: Excellent radio frequency interference (RFI) rejection for stable signals
• Unthreaded Length: 0 inch (code 00)
• Overall Case Length: 1.5 inches (code 15)
• Total Probe Length: 1.0 meter (3.3 feet) - code 10
• Thread Type: 5/8-18 UNF without armor
• Cable: 75 Ω triaxial with FEP insulation
• Connector: Miniature coaxial ClickLoc connector with standard cable (code 02)
• Agency Approval: Multiple Approvals (code 05)
• DC Resistance at 1.0m: 5.9 ± 0.5 ohms
• Maximum Thread Engagement (5/8-18): 0.938 inch
• Maximum Thread Engagement (M16x1.5): 24 mm
• Maximum Thread Engagement (M14x1.5): 21 mm
• Recommended Torque: 15.2 N·m (133 in·lb)
• Maximum Torque: 45.2 N·m (400 in·lb)
• Connector Torque: Finger tight (max 0.565 N·m / 5 in·lb)
• Minimum Bend Radius: 25.4 mm (1.0 inch) with or without SST armor
• Shipping Weight: 0.17 kg

Frequently Asked Questions (FAQ)

• Q: Is this a genuine Bently Nevada probe?
  A: Yes, we supply a brand new, original 330707-00-15-10-02-05 made in the U.S.A.
• Q: What agency approvals does this model have?
  A: Code 05 means this probe carries multiple agency approvals for global use.
• Q: What is the maximum operating temperature?
  A: The probe works reliably from -52°C up to +177°C (-62°F to +351°F).
• Q: Does this probe include armor?
  A: No, this model uses a standard cable without SST armor.
• Q: How long does shipping take?
  A: We ship within 5 days using FedEx, UPS, or DHL for reliable service.
• Q: Can I return this probe if it does not fit my application?
  A: Yes, we offer a 30-day return window for new, uninstalled probes.
• Q: What is the total cable length?
  A: This probe includes a 1.0 meter (3.3 feet) integrated triaxial cable.
• Q: Do you pressure test probes before shipping?
  A: No, standard probes do not receive pressure testing. Contact us for custom testing.

Download the complete datasheet for technical reference: 3300 XL 11 mm Proximity Transducer System Datasheet (PDF)
