330702-00-24-50-11-00 Bently Nevada 3300 XL 5m Probe

Bently Nevada 330702-00-24-50-11-00: 3300 XL 11 mm Proximity Probe

Key Technical Specifications

• Brand & Model: Bently Nevada 330702-00-24-50-11-00 – 3300 XL 11 mm Probe.
• Unthreaded Length Option: 00 = 0 inches (no unthreaded section).
• Overall Case Length Option: 24 = 2.4 inches.
• Total Length Option: 50 = 5.0 meters (16.4 feet).
• Connector & Cable Type: 11 = Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable.
• Agency Approval Option: 00 = Not required for this unit.
• Probe Tip Material: Polyphenylene sulfide (PPS) resists harsh chemicals.
• Probe Case Material: AISI 304 stainless steel (SST) provides excellent corrosion resistance.
• Cable Specification: 75 Ω triaxial cable with FEP insulation. Available total lengths: 1, 5, or 9 meters.
• Operating & Storage Temperature: -51°C to +177°C (-60°F to +351°F). Exposure below -34°C may damage the pressure seal.
• Probe Pressure Design: Seals differential pressure between tip and case using a Viton O-ring. Not pressure tested before shipment.
• Shipping Weight: 0.17 kg (lightweight for easy handling).
• Probe DC Resistance (5.0m length): 7.2 ± 0.8 ohms (center conductor to outer conductor).
• Probe Case Thread: 1/2-20 UNF. Maximum thread engagement length: 0.750 inches.
• Maximum Case Torque: 45.2 N•m (400 in•lb). Recommended torque: 15.2 N•m (133 in•lb).
• Connector Torque: Finger tight recommended; maximum 0.565 N•m (5 in•lb).
• Minimum Bend Radius (with or without SST armor): 25.4 mm (1.0 inch).
• Alternative Metric Thread: M16x1.5 with 24 mm max thread engagement.
• Important Note: Five meter probes work only with the five meter Proximitor Sensor.

Frequently Asked Questions (FAQ)

• Is this probe brand new and original? – Yes, we supply only brand new original Bently Nevada parts. No refurbished or counterfeit items.
• Do you have the 330702-00-24-50-11-00 in stock? – Yes, we keep this model in stock for immediate order processing.
• What is the maximum temperature this probe withstands? – It operates from -51°C to +177°C (-60°F to +351°F). Avoid prolonged use below -34°C.
• Can I use this 5.0 meter probe with any Proximitor Sensor? – No, five meter probes work only with the five meter Proximitor Sensor. Standard sensors require 1m or 9m probes.
• How long does shipping take? – We dispatch within 5 days. Delivery time depends on FedEx/UPS/DHL service to your country.
• What is the return policy? – We support 30-day returns from delivery date, provided the item is unused and in original packaging.
• Is the probe pressure tested before shipping? – Bently Nevada does not pressure test standard probes. Contact our custom design department if you require a pressure seal test.
• What torque should I apply for the ClickLoc connector? – Finger tight only, maximum 0.565 N•m (5 in•lb). Over-tightening damages the connector.
