330192-00-10-90-05 Bently Nevada 3300 XL 8mm ETR Probe

Bently Nevada 330192-00-10-90-05 3300 XL 8 mm ETR Probe

• Brand & Model: Bently Nevada – 330192-00-10-90-05 (3300 XL 8 mm ETR Probe).
• Thread & Armor: 3/8-24 UNF thread with rugged armor for cable protection.
• Case & Unthreaded Length: Overall case length 0.8 inch; unthreaded length 0.0 inch (minimum).
• Total Cable Length: 9.0 meters (29.5 feet) for flexible installation.
• Agency Approvals: CSA, ATEX, IECEx – suitable for Class I, Zone 0/2 and Division 2 areas.

Key Technical Specifications

• Probe DC Resistance (RPROBE): 9.87 ± 0.50 Ω (center to outer conductor at 9.0 m).
• Tip Material: Polyphenylene sulfide (PPS) for chemical resistance.
• Case Material: AISI 303 or 304 stainless steel (SST).
• Thread Engagement Length: Maximum 0.563 inch for 3/8-24 threads.
• Relative Humidity: Less than 3% ASF change after 56 days at 93% RH (IEC 68-2-3).
• Operating Temperature (Standard): -52°C to +177°C (-62°F to +350°F).
• Extended Temperature (Tip): -52°C to +218°C (-62°F to +425°F).
• Extended Cable/Connector: -51°C to +260°C (-60°F to +500°F).
• Pressure Seal: Viton® O-ring seals differential pressure (not pressure-tested before shipment).

Hazardous Area Classifications

• Intrinsic Safety (ia): Ex ia IIC T5…T1 Ga; Class I, II, III (Groups A-G).
• Non-incendive (nA/ec): Ex nA IIC T5…T1 Gc; Class I, Zone 2 / Division 2.
• Temperature Schedule (Probe Only): T1 (-55°C to +232°C) to T5 (-55°C to +40°C).
• EPL Dc Temperatures: T280°C @ -55°C to +232°C; T90°C @ -55°C to +40°C.

Frequently Asked Questions (FAQ)

• Q: Is this probe new and original?
  A: Yes, we supply 100% new and original Bently Nevada probes.
• Q: Do you have this model in stock?
  A: Yes, we maintain stock for 330192-00-10-90-05 and ship within 5 days.
• Q: What is the maximum thread engagement?
  A: The maximum thread engagement is 0.563 inch for 3/8-24 UNF.
• Q: Can I use this probe in high humidity?
  A: Yes, it passes 56-day 93% RH testing with less than 3% scale factor change.
• Q: What is the pressure seal material?
  A: The seal uses a Viton® O-ring for differential pressure sealing.
• Q: Is pressure testing performed before shipping?
  A: Probes are not pressure-tested; contact our design team if required.
• Q: What approvals does this probe carry?
  A: CSA, ATEX, IECEx for Class I, Zone 0/2 and Division 2 hazardous areas.
• Q: What is the RPROBE value for 9.0 meters?
  A: The nominal DC resistance is 9.87 ± 0.50 Ω.
