330104-01-20-15-02-05 Armored Probe Bently Nevada

Bently Nevada 3300 XL 8mm High-Performance Proximity Probe 330104-01-20-15-02-05

Key Features and Design

• 10mm unthreaded shaft provides flexible installation options for various applications.
• 200mm heavy-duty housing ensures maximum durability in tough conditions.
• Global safety certifications include CSA, ATEX, and IECEx for hazardous areas.
• Viton® pressure sealing maintains performance under challenging environmental conditions.

Technical Specifications

• Brand: Bently Nevada
• Model: 330104-01-20-15-02-05
• Measurement Range: 1.27mm with ±0.02mm accuracy
• Output Signal: -24V DC with 50Ω impedance
• Operating Temperature: 64°F to 80°F (18°C to 27°C)
• Cable Resistance: 7.73Ω ±0.5 at 1.5 meter length
• Power Requirement: -17.5V to -26V DC input voltage
• Target Material: Compatible with AISI 4140 steel

Model Configuration Details

• Code 01 specifies the 10mm unthreaded sensing section.
• Code 20 indicates the 200mm long protective casing.
• Code 15 represents the standard 1.5 meter cable length.
• Code 05 confirms the triple global safety certifications.

Installation Guidelines

• Maintain approximately 50 mils gap distance from the target surface.
• Use M10×1 threaded connections for secure and proper mounting.
• Ensure input voltage remains above -23.5V DC for optimal performance.
• The probe works seamlessly with 3300-series 5mm and 8mm sensor systems.

Package Contents

• One complete proximity probe unit ready for installation.
• Stainless steel mounting hardware for secure attachment.
• Viton® O-ring seal kit for reliable environmental protection.
• We ship all orders via reliable carriers including FedEx, UPS, and DHL.

Frequently Asked Questions

• Is this sensor brand new and genuine? Yes, we supply only new, authentic Bently Nevada products.
• Do you have the 330104-01-20-15-02-05 in stock? We maintain stock of this model for immediate shipment.
• How quickly will my order ship? We process and ship all orders within five business days.
• What shipping methods do you offer? We use major carriers including DHL, FedEx, and UPS.
• What is your return policy? We provide a 30-day return period for customer satisfaction.
• What is the operating temperature range? The sensor operates between 64°F and 80°F (18-27°C).
• What target material does this probe work with? It is compatible with AISI 4140 steel targets.

Technical Resources and Support

• Download the complete product datasheet for detailed specifications: 3300 XL 8 mm Proximity Transducer System Datasheet
• Contact our technical team for application support at sales@nex-auto.com
