330102-36-80-10-02-05 Bently Nevada 3300 XL Armored Probe

Bently Nevada 330102-36-80-10-02-05 – 3300 XL 8 mm Proximity Probe

Core Technical Specifications

• Manufacturer: Bently Nevada (Baker Hughes).
• Model: 330102-36-80-10-02-05 – 3300 XL series.
• Thread: 3/8-24 UNF with armor; max engagement 0.563 in.
• Unthreaded Length: 3.6 inches; Overall Case Length: 8.0 inches.
• Total Length: 1.0 meter (3.3 feet).
• Connector: Miniature coaxial ClickLoc (standard cable).
• Agency Approvals: CSA, ATEX, IECEx (option 05).
• Tip Material: Polyphenylene sulfide (PPS).
• Case Material: AISI 303 or 304 stainless steel (SST).
• Linear Range: 2 mm (80 mils) from 0.25 to 2.3 mm.
• Gap Setting (Radial): -9 Vdc (~1.27 mm / 50 mils).
• DC Resistance (RPROBE): 7.59 ± 0.50 Ω (1.0m length).
• Field Wiring: 0.2 to 1.5 mm² (16-24 AWG), shielded triad.
• Max Wiring Length: 305 m (1000 ft) to monitor.

Environmental & Mechanical Ratings

• Operating Temp (Standard): -52°C to +177°C (-62°F to +350°F).
• Extended Temp (Tip): -52°C to +218°C (-62°F to +425°F).
• Extended Cable/Connector: -51°C to +260°C (-60°F to +500°F).
• Pressure Seal: Viton® O-ring (not pressure tested).
• Humidity: <3% ASF change after 56 days at 93% RH.
• Weight: 323 g/m (11.4 oz).
• Intrinsic Safety (ia): Class I, Zone 0 with zener barriers.
• Non-incendive (nA/ec): Class I, Zone 2 per drawing 140979.
• Temp Class (EPL Ga/Gc): T1 (-55 to +232°C) to T5 (-55 to +40°C).

Installation & Wiring Instructions

• Use 3-conductor shielded triad cable (16 to 24 AWG).
• Keep field wiring under 305 meters (1000 feet).
• Do not exceed 0.563 inch thread engagement.
• Avoid temperatures below -34°C (-30°F) to protect the seal.
• For intrinsic safety, follow drawing 141092 (zener barriers).
• For non-incendive, refer to drawing 140979.
• Set radial gap to -9 Vdc (~1.27 mm / 50 mils).

Package Contents

• 1x Bently Nevada 330102-36-80-10-02-05 Proximity Probe (1.0m).
• Integrated miniature coaxial ClickLoc connector.
• Standard armored cable assembly.
• No mounting accessories or brackets included.

Frequently Asked Questions (FAQ)

• Q: Is this probe 100% new and original?
  A: Yes, we supply only genuine Bently Nevada parts.
• Q: Do you have this model in stock?
  A: Yes, we keep the 330102-36-80-10-02-05 in inventory.
• Q: What is the shipping timeframe?
  A: We dispatch orders within 5 working days.
• Q: Which carriers do you use?
  A: We ship via DHL, FedEx, or UPS – you choose.
• Q: What is your return policy?
  A: We accept returns within 30 days of delivery.
• Q: Can I use this probe in Zone 0?
  A: Yes, with appropriate intrinsic safety barriers (ia).
• Q: What is the maximum field wiring length?
  A: You can run up to 305 meters (1000 feet).
• Q: Does this probe have ATEX approval?
  A: Yes, option 05 includes CSA, ATEX, and IECEx approvals.
