2711P-T12C10D2 PanelView Plus 6 Touch Terminal Allen-Bradley

Allen‑Bradley 2711P‑T12C10D2 PanelView Plus 6 12‑inch Terminal

Core Technical Specifications

• Display: 12‑inch active‑matrix TFT with 800 x 600 resolution and 18‑bit color graphics.
• Display Area: 246 x 184 mm (9.7 x 7.2 in.) for ample viewing space.
• Input Methods: Analog resistive touchscreen plus 40‑key numeric keypad for fast data entry.
• Memory: 128 MB RAM for runtime operations and application handling.
• Power Input: 24 VDC; max consumption 70 W (2.9 A), typical 39 W (1.6 A).
• Communication Port: DeviceNet for seamless networking with other industrial devices.
• Operating Temperature: 0 to 55 °C; storage from ‑20 to 70 °C for environmental versatility.
• Weight: 3.2 kg for easy handling and panel installation.

Connectivity and Integration

• The integrated DeviceNet port supports smooth communication with PLCs and other automation equipment.
• Touchscreen and keypad combination offers flexible input options for operators.
• Compatible with various industrial networks through optional communication modules.
• Supports standard HMI functionality for monitoring and controlling automated processes.

Installation and Mechanical Design

• Lightweight design at 3.2 kg simplifies mounting in control panels or workstations.
• Operates reliably in temperatures from 0 to 55 °C for demanding industrial environments.
• Storage temperature range of ‑20 to 70 °C protects during transport and storage.
• Rugged construction suitable for factory floor applications.

Package Contents

• 2711P‑T12C10D2 operator terminal with integrated touchscreen and keypad.
• Mounting clips and gasket for panel installation.
• Power terminal block and grounding hardware.
• Quick‑start guide and calibration instructions.
• No additional software or memory card included.

Shipping & Logistics

• We ship all orders within 5 business days via FedEx, UPS, or DHL.
• All units are brand new, factory‑sealed, and in original packaging.
• Tracking information provided immediately after dispatch.
• International shipping available with full customs documentation.
• Stock is available for immediate order processing.

Frequently Asked Questions (FAQ)

• Is the 2711P‑T12C10D2 still in production?
  This model is available as new old‑stock and surplus units with full function guarantee.
• What communication protocols does it support?
  DeviceNet natively; optional modules support additional networks like Ethernet or DH+.
• Can I connect a keyboard or mouse?
  This model does not include USB ports; input is via touchscreen and keypad only.
• What is the power consumption?
  Maximum 70 W (2.9 A) and typical 39 W (1.6 A) at 24 VDC.
• What is the return policy?
  We accept returns within 30 days of delivery for a full refund (buyer pays return shipping).
• How do I transfer applications?
  Use the DeviceNet port or optional communication modules with appropriate software.
• Is the touchscreen replaceable?
  The touchscreen is integrated; the display module must be replaced if damaged.
