2711P-T10C4A8 Allen-Bradley PanelView Plus 6 1000 HMI Touch

2711P-T10C4A8 PanelView Plus 6 1000 Touch Terminal

• Display & Resolution: 10.4-inch color active-matrix TFT with 640 x 480 resolution. The screen delivers 18-bit color graphics and a viewing area of 211 x 158 mm (8.3 x 6.2 in.).
• Backlight & Longevity: CCFL backlight with a minimum 50,000-hour life at 25 °C (77 °F). This backlight is field-replaceable, simplifying long-term maintenance.
• Touchscreen Durability: Analog resistive technology supports 1 million actuations. An operating force of 10-110 grams ensures consistent response.
• Memory & Storage: 512 MB of RAM and 512 MB of internal Flash memory. This ample storage handles complex applications and data logging.
• Power Specifications: Operates on 100-240 VAC input, 50-60 Hz. Maximum power consumption is 160 VA, with typical usage lower.

Communication & Connectivity

• Ethernet & RS-232 Ports: One RJ45 Ethernet port supports EtherNet/IP for real-time messaging and I/O. One 9-pin RS-232 port handles DF1 and DH-485 protocols.
• Dual USB Host Ports: Two USB ports allow connection of a mouse, keyboard, or flash drive. This flexibility simplifies data transfer and system updates.
• Optional Network Modules: The terminal supports optional modules for DH+, DH-485, and ControlNet. This expands connectivity to legacy networks.

Physical & Environmental Features

• Weight & Dimensions: Shipping weight is 8 lbs. (3.6 kg). Box dimensions measure 16 x 14 x 8 inches (406 x 356 x 203 mm).
• Product Series: Available in Series A and B. The 2711P-T10C4A8 belongs to the PanelView Plus 6 product family.
• Rugged Construction: Use a protective screen overlay to guard against industrial contaminants. This preserves touch sensitivity and clarity.

Installation & Package Contents

• Mounting Instructions: Install the Allen-Bradley 2711P-T10C4A8 in a panel or enclosure. Follow the cutout dimensions and ensure proper ventilation.
• Box Contents: You will receive the terminal, mounting clips, and a quick-start guide. The communication cable (2711-NC13) is sold separately.
• Real-Time Clock: A battery-backed clock provides timestamping for critical data. The battery has a minimum life of 4 years.

Frequently Asked Questions (FAQ)

• Is this terminal new or refurbished? We supply 2711P-T10C4A8 units as brand new, factory-sealed products. All units are genuine Allen-Bradley inventory.
• Do you have this model in stock? Yes, we maintain stock of the Allen-Bradley 2711P-T10C4A8. We can ship most orders within 5 business days.
• What shipping carriers do you use? We ship via FedEx, UPS, and DHL. Choose your preferred option at checkout for reliable delivery.
• Can I return this product if it doesn’t fit my application? Yes, we support returns within 30 days of receipt. The unit must remain in original, unopened packaging.
• Does this terminal support DF1 protocol? Yes, the RS-232 port supports both DF1 and DH-485. This gives you flexible connectivity with legacy and modern controllers.
• Is the backlight replaceable in the field? Yes, the CCFL backlight is field-replaceable. This extends the service life of your 2711P-T10C4A8 terminal.
