25B-E3P0N104 - Allen-Bradley PowerFlex 525 Drive

Allen-Bradley PowerFlex 525 VFD: Compact Frame A Solution

Key Technical Specifications

• Brand: Allen-Bradley
• Model: 25B-E3P0N104
• Input Voltage: 446 to 660 V AC, Three Phase
• Output Current: 3.0 Amps
• Output Power: 1.5 kW (2.0 HP)
• Output Voltage: 0 to 575 V AC
• Frequency Range: 0 to 500 Hz
• Control Methods: PWM, V/Hz, Sensorless Vector, Closed Loop
• Communication: Built-in EtherNet/IP and RS485
• Enclosure: IP20 / NEMA Open
• Mounting: DIN Rail or Panel Mount

Signals and I/O Configuration

• Digital Inputs: 7 sink/source (6 programmable)
• Digital Outputs: 2 transistor outputs and relay contacts
• Analog Inputs: 2 inputs (0-10V or 0-20mA)
• Analog Output: 1 output (0-10V or 0-20mA)
• Resolution: Analog ~12 bit, Frequency step ~0.01 Hz
• Brake Support: Integrated brake resistor control
• EMC Filter: External filter recommended 25-RF8P0-BL

Operating Ranges and Environmental Limits

• Operating Temperature: -20°C to +50°C
• Storage Temperature: -40°C to +85°C
• Humidity Range: 5% to 95% non-condensing
• Altitude Rating: Full power to 1000 meters
• Switching Frequency: User settable from 2 kHz to 8 kHz
• Voltage Tolerance: +10% / -15% typical


Shipping & Packaging Details

• Product Condition: Brand New and Original
• Availability: In Stock for Immediate Shipping
• Processing Time: Ships Within 5 Business Days
• Shipping Methods: FedEx, UPS, DHL Available
• Package Contents: VFD unit and installation manual

Frequently Asked Questions (FAQ)

What is the power rating of this Frame A PowerFlex 525 model?

• The 25B-E3P0N104 delivers 1.5 kW (2.0 HP) for compact applications.

What input voltage range does this high-voltage drive support?

• This VFD operates on 446 to 660 V AC, three phase power input.

What control methods are available with this drive?

• It supports V/Hz, sensorless vector, closed loop vector, and PM motor control.

Does this model include an internal EMC filter?

• No, it requires an external EMC filter such as 25-RF8P0-BL for compliance.

What is the operating temperature range?

• This drive operates reliably from -20°C to +50°C ambient temperature.

Is this compact model available for quick delivery?

• Yes, we have this Frame A drive in stock ready for fast shipment.

For complete technical specifications and wiring diagrams, download the product manual.
Download the PDF guide here: PowerFlex 520-series AC Drive

For pricing and technical support, contact our sales team.
Contact: sales@nex-auto.com
