Bently Nevada 200152-25-00: 25-Meter Accelerometer Interface Cable

Complete Suffix Information – Bently Nevada 200152-25-00

• 200152 – Base series number (Bently Nevada)
• -25 – Fixed length: 25.0 meters
• -00 – Standard coupling nut configuration
• Connector end: Accelerometer end only, one connector pre-installed

Technical Specifications – Bently Nevada 200152-25-00

• Brand & Series: Bently Nevada 200152 industrial interconnect series
• Cable Type: Accelerometer interface standard cable, connector on accelerometer end only
• Length: 25.0 meters – extended reach for remote monitoring applications
• Conductor Design: 4 conductors, 22 AWG, tinned copper
• Shielding: Braided shield with ≥85% coverage minimum plus dedicated drain wire
• Outer Jacket: PVC, abrasion‑resistant industrial grade
• Coupling Nuts: Nickel‑plated, standard -00 configuration
• Minimum Bend Radius: 73.7 mm (2.9 in) – maintain during installation
• Connector Type: Molded to cable, IP67-rated when mated

Temperature Ratings & Flex Limitations

• Operating Temperature: –20 °C to +100 °C (–4 °F to +212 °F)
• Important limitation: Do not flex cable below –20 °C. Lower temperatures require static installation only.
• Flexing below –20 °C may cause permanent damage to conductors and jacket.
• Storage Temperature: –55 °C to +121 °C (–67 °F to +250 °F)
• Cure Time: 24 hours for DC4 compound full seal integrity

Environmental Sealing & Moisture Protection

• Mated Sealing: IP67 when properly mated to transducers or mating hardware
• Connector Construction: Fully molded to cable body – no exposed termination points
• DC4 Compound: Apply electrical insulating compound inside connectors
• Provides additional moisture protection during thermal shock events
• Requires 24 hours cure time for maximum environmental resistance
• Drain Wire: Dedicated ground path prevents moisture-induced noise

Download Official Bently Nevada Datasheet

• Complete specifications for 200150, 200155, and 200157 accelerometers
• Includes mechanical drawings, frequency response curves, and torque specifications
• Reference Figure 10 for -00 standard coupling nut dimensions
• → Download PDF: 200150-200157 Accelerometer Datasheet

Frequently Asked Questions – Bently Nevada 200152-25-00

• Is the Bently Nevada 200152-25-00 a genuine OEM product?
  Yes, we supply 100 % brand‑new, factory‑sealed 200152 cables. No aftermarket or refurbished units.
• What is the difference between -00 and -CN coupling nuts?
  The -00 configuration uses standard coupling nuts. The -CN suffix indicates country‑specific thread patterns for regional compatibility.
• Can I use this cable in sub-zero temperatures?
  Yes, but do not flex the cable below –20 °C. Static installations at lower temperatures are acceptable.
• Why does this cable have only one connector?
  The 200152-25-00 features connector-on-accelerometer-end-only design. This allows field termination at the instrumentation cabinet for customized installations.
• How quickly do you ship this 25-meter cable?
  We dispatch orders within 5 business days via FedEx, UPS, or DHL – you select preferred carrier.
• What is the purpose of DC4 compound cure time?
  The 24-hour cure time ensures DC4 insulating compound fully sets, providing maximum moisture protection during thermal shock conditions.
• What is your current inventory status for 200152-25-00?
  We maintain extensive stock of the 200152-25-00 and all length variants. Ready for immediate shipment.
