1734-EP24DC Allen-Bradley POINT I/O Expansion Power Supply

Allen-Bradley 1734-EP24DC POINT I/O Expansion Power Supply

Technical Specifications of 1734-EP24DC

• Brand & Model: Allen-Bradley 1734-EP24DC.
• Module Type: POINT I/O Expansion Power Supply.
• Nominal Input Voltage: 24V DC (acceptable range: 10-28.8V DC).
• Field Power: 24 Volts DC.
• Power Supply Current: 10 amps maximum.
• Inrush Current: 6 amps for 10 milliseconds.
• Continuous Isolation Voltage: 50 Volts.
• Overvoltage Protection: Reverse polarity protection (integral).
• Power Consumption: 9.8 Watts maximum @ 28.8V DC.
• Power Dissipation: 3.0 Watts @ 28.8V DC.
• Thermal Dissipation: 10.0 BTU/hour @ 28.8V DC.
• POINTBus Output Current (Horizontal Mounting): 1 A @ 10-19.2V input; 1.3 A @ 19.2-28.8V input.
• POINTBus Output Current (Vertical Mounting): 1 A @ 10-28.8V input.
• Operating Temperature: -13°F to 140°F (-25°C to 60°C).
• Nonoperating Temperature: -40°F to 185°F (-40°C to 85°C).
• Relative Humidity: 5% to 95% noncondensing.
• Operating Vibration: 5g at 10-500 Hz.
• Operating Shock: 30g; Nonoperating Shock: 50g.
• Mounting Orientation: Horizontal or vertical (follows POINT I/O system orientation).

Frequently Asked Questions (FAQ)

• Q: How many I/O modules can this power supply support?
  A: The 1734-EP24DC supports 4 to 17 POINT I/O modules on its right side. The exact number depends on the current draw of each module.
• Q: What is the POINTBus output current for vertical mounting?
  A: For vertical mounting, the 1734-EP24DC provides 1 A output across the entire 10-28.8V input range.
• Q: Does this module have overvoltage protection?
  A: Yes, the 1734-EP24DC includes integral reverse polarity overvoltage protection.
• Q: What is the inrush current rating?
  A: The module withstands an inrush current of 6 amps for 10 milliseconds.
• Q: Do you have stock for 1734-EP24DC?
  A: Yes, we keep the 1734-EP24DC in stock and ship within 5 business days.
• Q: What shipping methods do you use?
  A: We ship via FedEx, UPS, and DHL for fast and reliable delivery worldwide.
• Q: What is your return policy?
  A: We support 30-day returns for unused items in original condition.
• Q: Can I mount this power supply vertically?
  A: Yes, the 1734-EP24DC supports both horizontal and vertical mounting orientations.
