127A Input FANUC A06B-6140-H030 Servo Drive

FANUC A06B-6140-H030 High-Power Servo Amplifier Introduction

The FANUC A06B-6140-H030 is a substantial servo amplifier module designed for high-torque, high-power industrial applications. It acts as a critical power conversion unit, taking three-phase AC input and delivering regulated DC power for driving large servo or spindle motors.

Core Technical Specifications

• Brand: FANUC
• Model: A06B-6140-H030
• Product Type: Servo Amplifier Module
• Rated Output Power: 35 kW (as indicated by rated output current spec)
• Rated Input Voltage: 200 to 240 VAC
• Main Input Current: 127 A
• Rated Output Voltage: 283 to 339V DC

Input Power & Electrical Configuration

• Voltage Phase: 3-phase
• Input Frequency: 50/60 Hz
• Voltage Class: 200V
• The A06B-6140-H030 requires a high-current three-phase AC supply, typical for large industrial equipment.
• It converts this AC power to a high-voltage DC bus (283-339V), which is then used by downstream servo drives.

Physical & Dimensional Specifications

• Dimensions (H x W x L): 38 cm x 15 cm x 27.2 cm
• Weight: 25.00 lbs (11.34 kg)
• Its substantial size and weight reflect its high-power capacity and robust construction.
• Designed for mounting in large industrial control cabinets with adequate space and ventilation.

Application & System Role

• Functions as the main power supply amplifier within a multi-drive system, providing the DC link for one or more servo axes.
• Ideal for large CNC machining centers, heavy-duty milling machines, and large-scale industrial automation where high continuous power is required.
• Its 35kW rating makes it suitable for driving main spindles or multiple high-torque servo motors simultaneously.
• A key component in FANUC's high-performance motion control systems.

Installation & Setup Guide

• Install in a large, well-ventilated electrical cabinet that can accommodate its dimensions and weight.
• Connect a three-phase 200-240VAC power source using wiring and protection devices rated for 127A.
• Ensure the cabinet ambient temperature remains within standard industrial limits for optimal cooling.
• Connect the DC output terminals to the designated servo drive system's DC bus.
• Professional installation following FANUC's technical guidelines is strongly recommended due to the high power involved.

Packaging & Shipping Information

• The FANUC A06B-6140-H030 is shipped in a heavy-duty, custom-sized crate.
• Significant protective packaging is used to secure this large and valuable module during transit.
• The shipment includes the amplifier module.
• We coordinate freight shipping for this item globally via FedEx, DHL, and UPS freight services.

Frequently Asked Questions (FAQ)

• What is the power output? It provides a 35 kW rated output.
• What is the input current? It requires a 127 Amp three-phase input.
• What is the output voltage? It delivers a regulated 283-339V DC output.
• What are its physical dimensions? Dimensions are 38cm H x 15cm W x 27.2cm L.

For technical data sheets or to order the FANUC A06B-6140-H030, contact us.
