XNX-UTAV-NNIV1 Honeywell Gas Detector Multi-Sensor Transmitter

XNX-UTAV-NNIV1 Universal Gas Detector with Multi-Sensor Support

Core Technical Specifications

• Brand: Honeywell Analytics.
• Model Number: XNX-UTAV-NNIV1.
• Sensor Compatibility: mV (catalytic bead & IR cell), electrochemical, and IR (point/open-path).
• Default Sensor: MPD IR (IV1) for 0-100% LEL methane (or 0-5% Vol.).
• Output Signal: 4-20mA with HART® as standard.
• Communication Options: Up to 3 relays, MODBUS®, and FOUNDATION® H1 Fieldbus (pending).
• Local Interface: Optional IS port for handheld HART configurator.
• Wiring: 3 or 4-wire operation (source, sink, or isolated).
• Enclosure Rating: NEMA 4X and IP66 for rugged environments.
• Material: Aluminum (A) with corrosion-resistant finish.
• Conduit Entry: ¾" NPT (T) for cable or conduit installations.
• Approvals: UL and CSA certified.
• Dimensions: 16 x 19.7 x 11.4 cm (approx.).
• Weight: 2.8 kg.

Frequently Asked Questions (FAQ)

• Q: Is the XNX-UTAV-NNIV1 brand new and original?
  A: Yes, we supply only 100% genuine Honeywell transmitters with full factory warranty.
• Q: What sensors does this model support?
  A: It supports mV catalytic bead, mV IR cell, electrochemical, and IR (point/open-path) sensors.
• Q: What is the default sensor range?
  A: The pre-installed MPD IR sensor measures methane from 0-100% LEL (or 0-5% Vol.).
• Q: Do you have this transmitter in stock?
  A: Yes, we maintain stock of the XNX-UTAV-NNIV1 for quick dispatch.
• Q: How long does shipping take?
  A: We ship within 5 days; typical transit times are 2-5 business days with DHL, FedEx, or UPS.
• Q: Can I return the unit if it does not fit my system?
  A: Yes, we accept returns within 30 days of receiving the item.
• Q: Does this support MODBUS or Fieldbus?
  A: Yes, it offers MODBUS® and FOUNDATION® H1 Fieldbus (pending) as optional communication.
• Q: What is the enclosure rating?
  A: The aluminum housing is rated NEMA 4X and IP66 for rugged indoor/outdoor use.
• Q: Can I use this with a handheld configurator?
  A: Yes, the optional local IS port allows connection to a handheld HART® configurator.
