TC-POB041 Digital Output 4 Channels - Honeywell

Honeywell TC-POB041 4-Point Digital Output Module

• Output capacity: four channels referenced to a single supply, each with 11 V at 45 mA drive capability.
• Switching frequency: 10 kHz ensures fast on-off cycles for actuators and valves.
• Response time: 1 ms module input/output delay for real-time digital control.
• Failure state: de-energized state provides fail-safe operation during power loss.

Intrinsic Safety & Field Circuit Values

• Permissible output: Uo = 27.4 V, Io = 110 mA for safe field wiring.
• External inductance (Lo): 8 mH (IIB) / 2 mH (IIC) maximum.
• External capacitance (Co): 677 nF (IIB) / 87 nF (IIC) maximum.
• Certification: CENELEC II (1) 2G EEx ia/ib IIB/IIC T4, ATEX DMT 99 ATEX E 026 X.

Diagnostics & Fault Handling

• Fault detection: monitors lead breakage and short circuit on all channels.
• Fault indication: alarm signal via backplane bus and flashing red channel LED.
• Delay time: configurable for the entire module, applies to all four outputs.
• Latch mode: configurable for the module to retain fault status.

Galvanic Isolation & Environmental Protection

• Isolation: output / backplane bus and output / power supply (per DIN EN 50020).
• No inter-channel isolation: outputs share a common reference.
• Protection class: IP20 (requires IP54 or better housing for field use).
• Ambient range: -20°C to 70°C, 95 % RH non-condensing, G3 pollution gas tested.

Mechanical & Power Specifications

• Power consumption: one supply unit load; dissipation 5 W.
• Weight: 0.282 kg (0.62 lb) – lightweight for DIN-rail mounting.
• Dimensions: 76 x 94 x 46 mm (3.0 x 3.7 x 1.8 inches), keyswitch position 7.
• Shock & vibration: 15g shock, 2g @ 10–500 Hz vibration tested per IEC 68-2-6.

Installation & Shipping Information

• Cabling: use shielded multicore cables for EMC compliance per CE requirements.
• Mounting: install in an enclosure with IP54 or higher for outdoor environments.
• Delivery: we ship within 5 working days via FedEx, UPS, or DHL.
• Package includes: one Honeywell TC-POB041 module, terminal base, and mounting accessories.

Frequently Asked Questions (FAQ)

• Is this module brand new and original? – Yes, we supply 100 % new and original Honeywell TC-POB041 units.
• What is the typical shipping time? – We dispatch orders within 5 days after confirmation.
• Which carriers do you use? – We ship with FedEx, UPS, or DHL for global coverage.
• Can I return the module? – We accept returns within 30 days for unused items in original packaging.
• Do you have TC-POB041 in stock? – Yes, we maintain sufficient stock for immediate shipment.
